Technical Specifications

Audio Section
Stereo M ode
Continuous Average Power (FTC)

50 Watts per channel, @ < 0.07% THD, 20Hz - 20kHz,
both channels driven into 8 ohms

Five-Channel Surround Modes
Power Per Individual Channel

Front L&R channels:
40 Watts per channel
@ < 007% THE), 20Hz-20kHz into 8 ohms

Center channei:
40 Watts @ < 0.07% THD, 20Hz-20kHz into 8 ohms

Surround channels:
40 Watts per channel
@ < 0.07% THD, 20Hz-20kHz into 8 ohms

Input Sensitivity/Impedance
Linear (High»Levei) 200mV/47k ohms

Signal-to-Noise Ratio (IHF-A) 95dB
Surround System Adjacent Channel Separation

Pro Logic II 45dB

Doiby Digital (AC-3) 55dB

DTS 55dB
Frequency Response

@ 1W (+0dB, » 3dB)
High Instantaneous

10Hz- 100kHz

Current Capabiiity (HCC) :25 Amps
Transient Intermodulation

Distortion (TIM) Unmeasurable
Siew Rate ADV/usec

FM Tuner Section
Frequency Range
Usabie Sensitivity
Signal-to-Noise Ratio

B7.5-108.0M Hz
IHF1.3uV/13.2dBf
Mono/Stereo 70dB/68dB

Distortion Mono/Stereo 0.2%/0.3%
Stereo Separation 40dB @ 1kHz
Selectivity i400kHz, 70dB

Image Rejection SOdB

IF Rejection 90dB

AM Tuner Section

Frequency Range 520-1710kHz

Signal-to-Noise Ratio 45dB

Usabie Sensitivity Loop SOOuV
Distortion 1kHz, 50% Mod 0.8%
Selectivity ilOkHz, 30dB

Video Section
Television Format paI
Input Level/Impedance 1Vp»p/75 ohms
Output Levei/Impedance 1Vp»p/75 ohms
Video Frequency

Response 10Hz»8MHz i-3dB)
General
Power Requirement AC 230V/50Hz
PowerConsumption W idle, W maximum
(2 channels driven)
Dimensions
Width 17.3 inches (440mm)
Height 6.5 inches (165mm)
Depth 17.1 inches (435mm)
Weight 31ibi14_1kg)

Depth measurement includes knobs, buttons and terminal connections.
Height measurement inciudes feet and chassis.
Ail features and specifications are subject to change without notice.
