Harman kardon avr 2000 owners manual
This is the 48 pages manual for harman kardon avr 2000 owners manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from harman kardon avr 2000 owners manual (Ocr-read)
Page 1
2TABLE OF CONTENTS 3 Introduction 4 Safety Information 5 Front Panel Controls 7 Front Panel Information Display 9 Rear Panel Connections 11 Remote Control Functions 14 Installation and Connections 14 Audio Equipment Connections 14 Video Equipment Connections 15 SCART A/V Connections 16 System and Power Connections 17 System Configuration 17 Speaker Selection and Placement 18 First Turn On 18 Settings to be Made With Each Input Used 18 Input Setup 18 Speaker Setup 20 Surround Setup 20 Making Settings independent of selected Input 20 Delay Settings 21 Night Mode Settings 21 Output Level Adjustment 23 Operation 23 Basic Operation 23 Source Selection 23 Controls and Use of Headphones 24 Surround Mode Chart 25 Surround Mode Selection 25 Digital Audio Playback 25 Dolby Digital 25 DTS 25 PCM Audio Playback 26 MP3 Audio Playback 26 Selecting a Digital Source 26 Digital Status Indicators 27 Night Mode 27 Important Notes on Digital Playback 27 Tape Recording 28 Output Level Trim Adjustment 28 Display Brightness 28 Memory Backup 29 Tuner Operation 30 RDS Operation 32 Programming the Remote 32 Programming the Remote with Codes 33 Macro Programming 34 Programmed Device Function 34 Volume Punch-Through 35 Channel Control Punch-Through 35 Transport Control Punch-Through 35 Resetting the Remote Memory 36 Function List 38 Setup Code Tables 46 Troubleshooting Guide 46 Processor Reset 47 Technical Specifications Table of Contents Typographical Conventions In order to help you use this manual with the remote control, front-panel controls and rear-panel connections, certain conventions have been used. EXAMPLE – (bold type) indicates a specific remote control or front-panel bu\ tton, or rear-panel connection jack EXAMPLE – (OCR type) indicates a message that is visible on the front-panel\ information display 1 – (number in a square) indicates a specific front-panel control – (number in a circle) indicates a rear-panel connection 0 – (number in an oval) indicates a button or indicator on the remote A – (letter in a square) indicates an indicator in the front-panel display\ Declaration of Conformity We, Harman Consumer International 2, route de Tours 72500 Château-du-Loir, FRANCE declare in own responsibility, that the product described in this owners manual is in compliance with technical stan- dards: EN 55013/6.1990 EN 55020/12.1994 EN 60065:1993 EN 61000-3-2/4.1995 Carsten Olesen Harman Kardon Europe A/S 11/00
Page 2
INTRODUCTION3 Introduction Thank you for choosing Harman Kardon! With the purchase of a Harman Kardon AVR 2000 you are about to begin many years of lis- tening enjoyment. The AVR 2000 has been cus- tom designed to provide all the excitement and detail of movie sound tracks and every nuance of musical selections. With onboard Dolby* Digital and DTS †decoding, the AVR 2000 deliv- ers six discrete channels of audio that take advantage of the digital sound tracks from the latest DVD and LD releases and Digital Television broadcasts. While complex digital systems are hard at work within the AVR 2000 to make all of this happen, hookup and operation are simple. Color-keyed connections and a programmable remote con- trol make the AVR 2000 easy to use. To obtain the maximum enjoyment from your new receiv- er, we urge you to take the time to read through this manual. This will ensure that connections to speakers, source playback units and other exter- nal devices are made properly. In addition, a few minutes spent learning the functions of the various controls will enable you to take advan- tage of all the power the AVR 2000 is able to deliver. If you have any questions about this product, its installation or its operation, please contact your dealer. He is your best local source of informa- tion. Description and Features The AVR 2000 is among the most versatile and multi-featured A/V receivers available, incorpo- rating a wide range of listening options. In addi- tion to Dolby Digital and DTS decoding for digi- tal sources, a broad choice of analog surround modes are available for use with sources such as CD, VCR, TV broadcasts and the AVRs own FM/AM tuner. Along with Dolby Pro Logic* , Dolby 3 Stereo, 5 Ch Stereo and custom Hall and Theater modes, only Harman Kardon receivers offer Logic 7 ®to create a wider, more enveloping field environment and more defined fly-overs and pans. Finally, the AVR 2000 is among the very few A/V receivers that offer decoding of MP3 data, so that you may listen to the latest music selections directly from compatible com- puters or playback devices with the power and fidelity you expect from Harman Kardon. Another Harman Kardon exclusive is VMAx ™, which uses proprietary processing to create an open, spacious sound field even when only two front speakers are available. In addition to providing a wide range of listening options, the AVR 2000 is easy to configure so that it provides the best results with your speak- ers and specific listening-room environment. For the ultimate in flexibility, the AVR 2000 fea- tures connections for five video devices, all with both composite and S-Video inputs. Two addi- tional audio inputs are available, and a total of six digital inputs make the AVR 2000 capable of handling all the latest digital audio sources. Coax and optical digital outputs are available for direct connection to digital recorders. The AVR 2000s powerful amplifier uses traditional Harman Kardon high-current design technologies to meet the wide dynamic range of any program selection. Harman Kardon invented the high-fidelity receiv- er more than forty-seven years ago. With state- of-the-art circuitry and time-honored circuit designs, the AVR 2000 is one of the finest receivers ever offered by Harman Kardon in its price range. Onboard Dolby Digital and DTS Decoding Using Crystal ®Chip Technology Harman Kardons Exclusive Logic 7 and VMAx Modes MP3 Decoding for Use with compatible Computers and Digital Audio Players Front-Panel Digital Inputs for Easy Connection to Portable Digital Devices and the Latest Video Game Consoles Multiple Digital Inputs and Outputs Remote with Internal Codes Capability
