Harman kardon avr 100 owners manual
This is the 35 pages manual for harman kardon avr 100 owners manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from harman kardon avr 100 owners manual (Ocr-read)
Page 1
2 TABLE OF CONTENTS 3 Introduction 4 Safety Information 4 Unpacking 5 Front-Panel Controls 7 Front-Panel Information Display 8 Rear-Panel Connections 10 Remote Control Functions 13 Installation and Connections 15 System Configuration 19 Operation 19 Basic Operation 19 Source Selection 20 Surround-Mode Selection 21 Surround-Mode Chart 22 Tuner Operation 23 Tape Recording 23 Output-Level Trim Adjustment 23 6-Channel Direct Input 23 Memory Backup 24 Programming the Remote 24 Direct Code Entry 24 Auto-Search Method 24 Code Readout 25 Programmed Device Functions 25 Resetting the Remote Memory 25 Reassigning the DVD Button 27 Function List 28 Setup Code Tables:TV 30 Setup Code Tables:VCR 32 Setup Code Tables:DVD 33 Setup Code Tables:LD 34 Troubleshooting Guide 34 Processor Reset 35 Technical Specifications AVR 100 Audio/VideoReceiver Typographical Conventions In order to help you use this manual with the remote control,front-panel controls and rear-panel connections,certain conventions have been used. EXAMPLE– (bold type) indicates a specific remote control or front-panel button,or rear-panel connection jack EXAMPLE – (OCR type) indicates a message that is visible on the front-panel information display EXAMPLE– (outlined type) indicates a lit indicator in the front-panel information display 1 – (number in a square) indicates a specific front-panel control a – (number in an oval) indicates a button or indicator on the remote ¡ – (number in a circle) indicates a rear-panel connection A – (letter in a square) indicates an indicator in the front-panel display
Page 2
3 INTRODUCTION Introduction Thank you for choosing Harman Kardon! With the purchase of a Harman Kardon AVR 100 you are about to begin many years of listening enjoyment.The AVR 100 has been cus- tom designed to provide all the excitement and detail of movie sound tracks and every nuance of musical selections.With onboard Dolby* Digital,the AVR 100 delivers six discrete chan- nels of audio that take advantage of the digital sound tracks from the latest DVD and LD movies and Digital Television (DTV/HDTV) broadcasts. While complex digital systems are hard at work within the AVR 100 to make all of this happen,hookup and operation are simple. Color-keyed connections and a programmable remote control make the AVR 100 easy to use. To obtain the maximum enjoyment from your new receiver,we urge you to take a few min- utes to read through this manual.This will ensure that connections to speakers,source playback units and other external devices are made properly.In addition,a few minutes spent learning the functions of the various con- trols will enable you to take advantage of all the power the AVR 100 is able to deliver. If you have any questions about this product, its installation or its operation,please contact your dealer or custom installer.They are your best local source of information. Description and Features The AVR 100 is a full-featured A/V receiver, incorporating a wide variety of listening options.In addition to Dolby Digital decoding, Dolby Pro Logic* and Dolby 3 Stereo are available for compatibility with the tens of thousands of movies and television programs encoded with analog surround information.In addition,specially programmed Theater and Hall modes are available to enhance the enjoyment of conventional two-channel stereo recordings. A total of four audio/video inputs,as well as three additional audio-only inputs,are selected through a learning remote control and an easy- to-read front-panel display. The AVR 100s powerful amplifier uses traditional Harman Kardon high-current design technologies to meet the wide dynamic range of any program selection. Harman Kardon invented the high-fidelity receiver more than forty-five years ago.With state-of-the-art circuitry and time-honored circuit designs,the AVR 100 is one of the finest receivers ever offered by Harman Kardon. ■Onboard Dolby Digital Decoding ■Coax and Optical Digital Inputs ■Programmable Remote Control ■Composite Video Switching ■6-Channel Direct Input for use with external surround decoders or DVD-Audio CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: To prevent electric shock, do not remove the grounding plug on the power cord, or use any plug or extension cord that does not have a grounding plug provided. Make certain that the AC outlet is properly grounded. Do not use an adapter plug with this product. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated dangerous voltage within the products enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
