Hafler VRM 5 VRM 6 VRM 25 VRM 26 Owners Manual
This is the 16 pages manual for Hafler VRM 5 VRM 6 VRM 25 VRM 26 Owners Manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from Hafler VRM 5 VRM 6 VRM 25 VRM 26 Owners Manual (Ocr-read)
Page 1
– 1 – Introduction Thank you and congratulations on your purchase of the HAFLER VRM series of satellites. The VRM series are two- way passive speakers primarily used for front stereo, center channel, or rear surround channel applications. They are designed for use with high quality Hafler power amplifiers. The VRM5 and VRM6 are optimized for front stereo and rear surround applications. The VRM5 uses a 1 tweeter with a 5 driver and the VRM6 uses a 1 tweeter with a 6 driver. The VRM25 and VRM26 are optimized for front stereo towers and center channel applications. The VRM25 uses a single 1 with dual 5 drivers and the VRM26 uses a single 1 with dual 6 drivers. Although the VRM satellites are passive models they have technical circuitry and features that ensure excellent sound quality in every application. Crossover design is a 24dB/octave Linkwitz Riley that filters high frequencies to the tweeter and low frequencies to the woofer. The 6driver utilizes a Zobel network to extend the high frequency range and a parallel conjugate network to maintain Minimal Impedance Deviation (MID). The tweeter circuit also incorporates optical protection for overload protection and a 0dB/-3dB tweeter pad to match the tweeter level to the midrange for the best balance in sound. Combine the Ebony Ash Vinyl finish with the technical features and youll see the HAFLER VRM series provide the home theater enthusiast with loud levels, excellent sonic quality, and wide dynamic range, with excellent power handling and a stylish look.
Page 2
– 2– INTRODUCTION 1 TABLE of CONTENTS 2 PERFORMANCE SPECIFICATIONS 3 TECHNICAL DESIGN FEATURES 4 INSTALLATION Typical Studio Installations 5 High Performance Home Theater Installations 5 Location 6 SERVICE POLICY & LIMITED WARRANTY 7 SAFETY PRECAUTIONS 8 Table of Contents
Page 5
– 5– center channel left right left surround right surround subwoofer preamp/receiver front stage rear surround center channelsubwoofer Typical Home Theater System This system uses a receiver with that has built-in amplification Installation High Performance Home Theater System This system uses a receiver with dedicated amplification
