Hafler P1500 P3000 Owners Manual
This is the 28 pages manual for Hafler P1500 P3000 Owners Manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from Hafler P1500 P3000 Owners Manual (Ocr-read)
Page 1
Declaration of Conformity Application of Council Directive:73 / 23 / EEC (Low Voltage Directive) 89 / 336 / EEC (EMC Directive) Standard(s) to which Conformity is Declared: EN55103-1 EN55103-2 EN60065 Manufacturers Name: Hafler Manufacturers Address: 546 South Rockford Drive, Tempe, Arizona 85281 Importers Name: Importers Address: Type of Equipment: 2-channel Audio Power Amplifier/Speaker Model No.: P1000CE P1500CE P3000CE P4000CE 9505CE TRM6CE TRM8CE TRM10sCE TRM12sCE Year of Manufacturing: 1999 2000 2001 2002 2003 Serial Number: I, the undersigned, hereby declare that the equipment specified above conforms to the above Directive(s) and Standard(s) Place: Hafler Date: 09/01/1999 James C. Strickland, VP Engineering
Page 2
P ERFORMANCE S PECIFICATIONS P1500/P3000 Frequency Response: 20Hz to 20kHz, ±0.1dB 0.15Hz to 300kHz, +0/–3dB Signal-to-Noise: >100dB A Weighted Distortion: <0.2% 20-20kHz, typically .01% at 1kHz @ rated power into 8 Ω Slew Rate: 100 V/µs CMRR: 75dB at 1kHz Input Impedance: 47k ohms per phase Gain: +14dB min. +29dB max. P1500 Power Rating: 75 wpc @8 Ω, 85 wpc @ 4 Ω, 170 Watts mono @ 8Ω Damping Factor: 350 (to 1kHz); 150 (to 10kHz); 18 (to 100kHz) Input Sensitivity Range: 870mV - 4.8V (for 75 W @ 8 Ω) 650mV - 3.7V (for 85 W @ 4 Ω) Power Consumption: 60W / 500mA @ 120 VAC (Idle Power) 230W / 1.9A @ 120 VAC (1/8 Power – 8 Ω) 325W / 2.70A @ 120 VAC (Max. Power – 8 Ω) Dimensions: 19"W x 8-1⁄2"D x 3-1⁄2"H (2-rack spaces) (48.26cm x 21.59cm x 8.89cm) Net Weight: 22 lbs. (9.98kg) P3000 Power Rating: 150 wpc @8 Ω, 200 wpc @ 4Ω, 400 Watts mono @ 8 Ω Damping Factor: 400 (to 1kHz); 200 (to 10kHz); 18 (to 100kHz) Input Sensitivity Range: 1.2V - 6.9V (for 150 W @ 8 Ω) 1.0V - 5.6V (for 200 W @ 4 Ω) Power Consumption: 120W / 1.00A @ 120 VAC (Idle Power) 350W / 2.9A @ 120 VAC (1/8 Power – 8 Ω) 600W / 5.00A @ 120 VAC (Max. Power – 8 Ω) Dimensions: 19"W x 9-7⁄8"D x 3-1⁄2"H (2-rack spaces) (48.26cm x 25.08cm x 8.89cm) Net Weight: 23 lbs. (10.43kg) – i – 16.00 19.00 .717 hort t e m al c p pg signal c ann l 115 1 0 B 1 6 3 cha nel 215 1 0dB 10 6 3 atransP1500 signal c ppi g therm al s ot 3.470 8.410 17.00 19.00 .717 hort h erm al c ppi g s ig n al chan el 15 1 dB 0 6 3 ch nnel 21 1 0 B 10 6 3 atransP1500 sgn al c l ppin g t emal s ot 3.470 9.860 P1500 P3000
Page 26
N OTES
Page 27
MAN-1461-C 4/99 E.W.R. ® HAFLER A DIVISION OF ROCKFORD CORPROATION 546 SOUTH ROCKFORD DRIVE TEMPE, ARIZONA 85281 U.S.A. 480-967-3565 / 1-888-HAFLER1 WWW.HAFLER.COM
