Grundig Sonoclock S 230 Service Manual
This is the 3 pages manual for Grundig Sonoclock S 230 Service Manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Page: 1 / 3
Extracted text from Grundig Sonoclock S 230 Service Manual (Ocr-read)
Page 1
SonoClock S 230
Page 2
SonoClock S 230 ALIGNMENT FM RF Oscillator Aerial band passINPUT SIGNAL SOURCE Testpoint TP1 & TP2 GNDSIGNAL 87.35MHz 108.25MHz 88MHz 106MHzOUTPUT SpeakerSET RADIO Lowest end Highest end 88MHz 106MHzADJUST L103 VCT1B L102 VCT1AADJUST FOR MaximumREMARK Repeat this adjustment
