Page 1
ver 1.0 2 22 2 ~ÄëçäìíÉ=ÑáÇÉäáí ó Owners Manual and Set-up Guide: Genesis 7.1 Petite Loudspeaker Contents 1 A QUICK START SET-UP GUIDE 4 1.1 U NPACKING 4 1.2 P LACEMENT 4 1.3 C ONNECTIONS 4 1.4 A DJUSTMENTS 5 2 SETTING UP AS STEREO PAIR 6 2.1 P OSITIONING 6 2.2 L OUDSPEAKER CONTROLS 6 2.2.1 T WEETER CONTROL 6 2.2.2 B ASS CONTOUR 7 2.2.3 T WEETER DEFEAT 7 2.3 T UNING THE SYSTEM 7 2.4 O NE CHANGE AT A TIME 7 2.5 I MAGING AND SOUNDSTAGE 8 2.6 D EFINING THE SOUNDSTAGE 9 2.7 R OOM TREATMENT 10 2.8 M ASTERING THE REFINEMENTS OF THE SYSTEM 11 3 SETTING UP: MULTI-CHANNEL 12 3.1 P OSITIONING AS M AIN LEFT /R IGHT CHANNEL 12 3.2 P OSITIONING FOR CENTER CHANNEL 12 3.3 P OSITIONING FOR SURROUND CHANNEL 12 4 THE TECHNOLOGY USED 13 4.1 D IPOLAR CONFIGURATION 13 4.2 T HE TRANSDUCERS 13 4.2.1 T HE GENESIS RIBBON TWEETER 13 4.2.2 T ITANIUM M ID-W OOFER 14 4.3 C ROSSOVER 14 4.4 V IBRATION -FREE CABINET 14 5 SPECIFICATIONS 16
Page 2
ver 1.0 3 33 3 ~ÄëçäìíÉ=ÑáÇÉäáí ó A Message from Genesis Congratulations! You are now the owner of one of the finest loudspeakers in the world. The Genesis 7.1 Petite (G7.1p) features the worlds first solid titanium cone mid-woofer, and shares technologies developed for our flagship Genesis 1.1. The G7.1p is designed to be as flexible as possible. It can be used as a pair of audiophile stereo loudspeakers or, in a multi-channel system, can also be used as main left/right speakers, or as surround or rear channels. So that it will fit into the décor of any home, the cabinet design is a combination of acoustic, furniture, interior design and architectural principles. Care was taken in the selection of fine furniture-quality natural wood veneer finishes, and high-gloss Italian or automotive finish. Sound structural engineering principles have been applied to make the G7.1p cabinet rigid and well damped. All construction is of ¾ inch MDF and panels have been tongue and grooved to ensure that the cabinet is the best environment on which to mount the transducers. This results in extremely low cabinet coloration, and excellent soundstaging and imaging. The proportions are also designed to be visually pleasing and elegant. Please read this Owners Manual and Set-up Guide to get the maximum enjoyment out of your purchase. Also, check out our website at www.genesisloudspeakers.com for the latest updates, tips & tricks, and support for our owners. Please write the serial number and purchase details of your Genesis 7.1c here for future reference. Purchased at: _________________ Date: __________
