ZERO 92

Page 2

Garrard Engineering Limited Newcastle Street Swindon Wiltshire England

DESCRIPLOBL 7 7 7 2
EACKING US: 7 Ti 7 g
SETTING JP 77 7 9
QRERATING IN§T_R_UQT|0NS7 79
MTLNE MAINTENANCE 7 7 7 7172
SERVICE HINTS 7 173
ADJUSTMENTS 7 77 7 174
SPARE PARTS ANQ SERVICE 15

3W
ZERO 92

AUTOMATIC TRANSCRIPTION TURNTABLE

Page 11

10

GENERAL ADVICE

1 Keep the cartridge stylus clean and replace
it when worn. Your dealer will give further
advice on this.

2 Store and clean records as their manufac-
turers recommend. Do not leave records on
the turntable for long periods after use.

3 Do not switch on unless there is at least one
record on the turntable.

4 Do not hold or turn the platter counterclock-
wise.

5 Always allow the unit to switch itself off, or
switch it off manually by one of the operating
controls. It the power supply is disconnected
during play, the rubber intermediate wheel
will remain under pressure and may be de«
formed after a length of time in this con-
dition.

6 If the cartridge has more than one stylus,
make sure that the correct one is presented
for the record to be played.

PREPARING THE UNIT FOR USE AFTER
TRANSIT

Remove the stylus guard, if one is fitted.

1 Turn both transit screws fully clockwise so
that the unit floats freely on its spring
mountings.

2 Move the tonearm locking lever to FREE.

3 Check that all three operating tabs are up-
right.

Reverse instructions 1, 2 and 3 before the unit

is transported again.

Diagram 16 Transit Screw and Locking Lever

INSTRUCTIONS FOR USE

To play a single record manually

1 Fit the short, single record spindle into the
centre of the platter and turn the spindle
until it can be pressed down into place.

2 Place a record on the platter, using the
adaptor provided it the record has a large
centre hole.

3 Set the record speed selector to 33;, 45 or
78 rev/min as required by the record to be
played, and the cartridge tilting lever to M.

4 Move the manual operating control tab fully
to ON.

5 (a) Lower the tonearm onto the record by
hand lifting it at the front of the arm

_ or _
(b) Move the cueing control tab to LIFT,
then place the tonearm over any desired
point on the record and return the con-

trol tab towards PLAY to lower the tone-
arm gently.
Atter playing the record the tonearm will
return to its rest and the unit will switch off.

To play a slngle record automatically

1 Fit the short, single record spindle and place
the record on the platter, using the adaptor
provided if the record has a large centre
hole.

2 Set the record speed and size selector for
the record to be played. For example. 33 12
for a 332; rev/min 12in record.

3 Set the cartridge tilting lever to M.

4 Move the automatic operating control fully
to START and hold it there for a second or
two before releasing it. After playing the
record the tonearm will return to its rest and
the unit will switch off.

Lever shown at M
tor Slnnlo Record

l
Diagram 11 Cartridge Tilting Lever {
