Garrard Catalogue 1972

Page 1

n»
Fits?

Page 2

For more than 50 years Garrard has led the world in turn-
table technology and provided millions of peOple with
countless hours of listening pleasure. Thorough research,
creative product development and rigid quality control.
have assured Hi-Fi enthusiasts and equipment manufac-
turers of consistent quality. Makers of the worlds finest
record players, radiograms and Hi-Fi systems have
repeatedly made Garrard turntables the automatic choice
for their equipment

Garrard has pioneered and introduced virtually every sig-
nificant new feature in record playing units making con-
siderable contributions to the present high standards of
high fidelity. Two Queen' 5 Award to Industry the
Mercurio d Oro" (italy) and Maker of the Microphone"
(U. S. A.) are awards presented to Garrard as a result of
their engineering achievement and progressiveness.

The Garrard Zero-100 is truly a major advance in turn-
table technology and follows the Garrard tradition of

effective, stylish and attractive presentation as all other
models shown in this brochure.

Zero-100

A two-speed transcription quality changer providing automatic play oi up to six

rocora. incorporates a unique pickup arm design that virtually eliminates tracking
Arm employs a linkage which ivots the pleyi ng head to maintain the stylus

bar tangential to the record groove. ther teatures include magnetic bias compeno

setlon. vlwous damped cuelng device. variable speed control (+ 3%). magnetic

anti-etating control and illuminated stroboscope.

m: id":ldeby12%"tronttsrearby1" aboveand2X.~helenlomeredgeot

lilo-1008 (single player version - not illustrated)

A superb trumtptlon minim unit with the tacllity for automatic play at single
records. incorporates the some cunt-«ling features as the Zero too.

Note 1: Slim-promo flndier hoses to suit all models and replacement "Pickering"
cartridges are available item the Diswlhutors listed below.

Page 3

SL958

Weight counterbalanced pickup arm with afrormosia wood insert ensures effective low
resonance damping. Gimbal type pivots and slide-in cartridge carrier are additional
features. Calibrated pickup arm bias compensation and fine stylus lorce adjustment are
incorporated and the pickup arm can be locked on its rest. Further refinements are cue
and pause facility. automatic play of single records and finger-tip tab controls.

Size: 15.5/16" wide by 14.1/8" front to rear by 4.1/8" above and 2.15/16" below lower
edge of unit plate.

SL728

This unit features a weight counterbalanced pickup arm with gimbal type pivog. a
slideoin cartridge carrier. integral calibrated stylus force adjustment and bias om-
pensator. For automatic play of single records the easy-to-operate Auto" tab control
is simply moved to Start" when the arm will position itself on the record and after
playing will return to its rest. The unit will then shut off.

Size: 14.9/16" wide by 12.11/16" front to rear by 4.1/16" above and 2.15/16" below
lower edge of unit plate.

SL658

A three-speed automatic record changer fitted with an aluminium turntable and featuring
cue and pause control which gently raises or lowers the pickup when the unit is used
for playing records singly. The pickup arm is weight counterbalanced and incorporates
calibrated fine stylus force adjustment and bias compensation.

shunts/4» wide by 12.1/2" front to rear by 4.1/2" above and 2.15/16" below lower
edge of unit plate.

A876

A transcriptionoquality three-speed single record playing unit of exceptional elegance.
featuring automatic play and incorporatin fingertip tab controls for simplified operation.
Bias compensation. calibrated for spher cal and elliptical styli is adjustable. A com-
bined record-speed and size selector sets the unit for playing records automatically.

Size: 14.9/16" wide by 12.11/16" front to rear by 2.5/8" above and 2.15/16" below
lower edge of unit plate.
