Page 2

VF-16

Press the [ENTER/Y ES] key in the above display condition. The display indicates the free audio file numbers,

SERUICEBB
Freeblock Check

@881

if the Free Block indicates a large number even right afler formatting and no signal is recorded or if the recorded signal
on the E-lDE HDD is frequently skipped, the diskette / hard disk drive can be judged to be in a bad condition.

4-8. Product Initialize
This mode is exclusively used at our assembly line and has nothing to do with servicing the unit,

SEEUICEIB
Product Initial

-

UtsetDiSP U
Init.Disk I
FlashRDM

PEM:BI

Sure?

4-9. Key & LED Check Tests

These two tests are different from the before mentioned tests. It is not necessary to put the unit into the Service Mode
to execute these tests.

4-9-1. Key & LED Check

This test checks in which color the LEDS on the top panel is lit and if the key is correctly pressed or not. To execute,
press the CH9 (A) STATUS/CH SEL key while holding down the SHIFT and STOP keys, The LEDs are lit in the
following color.

©

6

m _,..._." VF-lb

m.
42:, _ .

1 mm

egg "mm. 5!"

-:n:n

15
