Focal FPS 1500 Service Manual
This is the 87 pages manual for Focal FPS 1500 Service Manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from Focal FPS 1500 Service Manual (Ocr-read)
Page 11
20 5103440010001 others 4.2 soldering ROHS 1 PCS
21 5103450010002 current-limitingresistor 20W0.01Q 2 PCS R22, R28 Line Diameter 1.5[withlocatorcard]
22 5104140020001 RUBBER MAT 30*15? ROHS 2 PCS
SAJ157anst parts
23 5105190040151 speakerterminals big 1 reverse black shell gold castings hexagon screw [.1511-52] 4 PCS
RDHS
SAJ153Z cast parts
24 5105190040152 speaker terminals big 3 reverse black shell gold castings hexagon screw [JSZ3-55] 1 PCS
RDHS
25 5 105200010003 Transparent plastic pillars L:25MM with taping ROHS 5 PCS
25 5105220020053 sheetcopper L:52.5MM[overall length] thiok1.2 four feet ROHS 2 PCS
27 5 105220020054 feet copper L:52.5mm[overall length] thick 1.2 Gold Plated RDHS 7 PCS
28 5212000000003 HeatShrinkTubing 2 Heat ShrinkTubing 0.258 M L:12mm 24PCS
29 5212010000003 HeatShrinkTubing 0.5 HeatShrinkTubing ROHS 0.12 M L:10mm12PCS
30 5 213000000005 Yellow Wax Tube 3 Yellow Wax Tube 0.2 M L:200mm For the magnetic ring
31 5213000000009 Yellow WaxTube 4YellowWaxTube 0.2 M L:200mm Forthemagneticring
32 5215070010010 tin bar there are leadIAnson] SnPb53/3? 0.038 K5
33 53010000700?7 Magnet 35 5:13[0.8*5/0.8*4] 2 PCS
34 5104010010013 magnetic core 35*15*23 ROHS 2 PCS
35 5204110010005 enamelled wire 0A-1 0.8 red 0.0514 KG Subprime :13cirtles /0.8*4
35 5204110010028 enarnelled wire 01-2 0.8 natural color 0.05 KB Subprime :5cificles/0.8*5
