FISHER® CR -W46

SPECIFICATIONS

' Motor (2) DC Governor
CAUTION Cassette Loading (2) Front

RISK F ELECTRIC Drive System (2) Capstan

SHDCKIDU NUT DPENI *-

Number of Heads 2/2

CAUTION: TO REDUCE THE RISK OF ELECTRIC such, Head Material Hard Perma'm/Fem"
DO NOT REMOVE COVER. Operation (2) Powered Mechanism

NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING T0 QUALIFIED SERVICE PERSONNEL.

This symbol Indicates that dangerous volt-
age constituting a risk of electric shock is
present within this unit,

This symbol indicates that there are impor-
tant operating and maintenance instructions
in the literature accompanying this unit.

it

Wowand Flutter
Signal-tmNoise Ratio (CCIR Weighted)

006%WRMS

Dolby NR OFF 51 dB
Dolby' NR ON 61 dB
Erase Ratio 70 dB
Channel Separation 40 dB
Signal Crosstalk 70 dB

Frequency Response 1-7/8 IPS

Normal Tape (:3 dB) 40 Hz- 13 kHz'
Cr02 Eouivalent Tape (:3 dB) 40 Hz - 1 4 kHz
MetalTape(=3 dB) 40 Hz-15kHz

Total HarmonicDistortion atOVU 1.2 Va

Fast Forward/Rewind Time (060) 1 10 sec.
Level indicators (2) LED Meters
Inputs (Sensitivity/Impedance) (2) Line

1 00 mV/SDkfl
Outputs (Level at 0 VU/lmpedance) (2) Line

500 mV/1.2 kfl

Normal, Cr02, Metal

Tape Selector Switch

Tape Counter Mechanical

GENERAL

Power Requirements .r! 120 VAC 110%
(50/60 Hz) , 1 2 Watts

Dimensions (WxHxD) 17.33x4.88x10.25

Weight (approx) 10 lbs.

Dolby is a registered trademark of Dolby Laboratories
LicensingCorporaIionr

Because its products are subject to continuous im-
provement, Fisher Corporation reserves the right to
modify product designs and specifications without
notice and without incurring any obligation.
