Fisher 510 Owners Manual
This is the 8 pages manual for Fisher 510 Owners Manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from Fisher 510 Owners Manual (Ocr-read)
Page 1
AVERY FISHER Foundq oad President, Fishu Radio Ctpora,ion The Mqn Behind the Product 1|vER 20 yEARS AGo, Avery Fisher introduced America's first high fidelity radio- \-/ phonograph. That instrument attained instant recognition as heralding a new era in the enjoyment of reproduced music. A number of the features of that early high fidelity radio-phonograph were so basic that they are used to this day in all high fidelity equipment. The engineering achievements of Avery Fisher and the world-wide reputation of his products have been the subject of articles in Fortune, Tin're, pageant, The New York Times, coronet, Lile, High Fidetity, Esquire, and other publications. Benefit concerts for the National Symphony orchestra in washington and the phila- delphia orchestra, demonstrating the great advances in reproducing equipment, used FISHER instruments to play back the recordings that had just been made in the presence of. the audience. "Fascinating evening, acoustically and musically," was the Philadelphia Inquirer's comment, "the reproduction had remarkable fldelity." Trve magazine stated, "Listeners could hardly tell the difference between real and electronic." The FISHER instrument you have just purchased has been designed to give you many years of pride and enjoyment. It is the product of a company dedicated to bringing reproduced music in its finest form, to the homes of America. If at any time you should desire information or assistance regarding the performance of your FISHER instru- ment, please do not hesitate to write directly to Avery Fisher, president, Fisher Radio coiporation, Long Island city 1, New York. Your communications will be welcome. FTSHER 'FIRSTS' - Milestones In Audio History.. . 1937 first high fidelity sound systems featuring a beaq-power amplifier, inverse feedback, acous- tic spealer compartments (intinite baffle and bass reflex) and magnetic cartridges. 1937 First exclusively high fidility TRF tuner, teaturins broad-tuning 20,000 cycle f idelity. 1937 First.twGunit high tidelity system with separate speaxer enct0sure. 1953 First FM-AM Receiver with a Cascode Front End. t954 First low-cost electronic Mixer-Fader. 1954 First moderately-priced, professional FM Tuner with TWo meters. 1955 First Peak Power Indicator in high fidelity. 1955 First Master Audio Control Chassis with five- position mtxtng tacilities, 1955 First correctly equalized, direct tape-head mas- ter audio controls and self-powered preamplifier. 1955 First to incorporate Power Monitor in a home amplifier. 1956 First All-Transistorized Preamplifier-Equalizer. 1956 First dual dynamic limiters in an FM tuner for home use. 1956 First Performance Monitor in a high quality amplifier for home use. 1956 First FM-AM tuner with TWO meters. 1956 First complete graphic response curve indicator lor Dass and treble. 1957 First cold Cascode FM Tuner. 1957 First MicroRay Tuning Indicator. 1958 First Slereophonic Radio-Phonograph with Mag- netic Stereo Cartridce t93E193Er93919391 9391 94tt 1 94E1 949r952r952t953 1953 First coaxial speaker system. First high tidelity tuner with amplified AVC. First Dynamic Range Expander. First $Way Speaker in a high fidelity system. First Center-of-Channel Tuning Indicator. First Preamplifier- Equalizer with selective pho- nograph equalization. First Dynamic Range Expander with feedback. Fitst FM-AM Tuner with variable AFC. First so-Watt, all-triode amplifier. First self-powered Master Audio Control. First self-powered, electronic sharp-cut-off fil- ter system for hiSih fidelity use. First Universal Horn-Type Speaker Enclosure for any room location and any speaker.
Page 2
THE FISHER dfrht.pl^** Series r'5IO" THE FISHER ,ll0 is a superb high fidelity instrument housed in an unusually attrac- tive furniture cabinet. It has been designed specifically for stereophonic reproduction in conjunction with THB FISHER Stereo Companion, in addition to its independent use as a complete monaural high fidelity phonograph. Simple plug-in receptacles are Pro' vided for the Stereo Contpotion and a variety of stereo or manaural progiam sources. THE FISHER Amplifier and Speaker System are capable of providing ample volume for all your needg without a trace of distortion, and the ea6y-to-use Stereo Control Center permits the sound to be adjusted to your personal tastes. Your phonograph records, stereophonib and monaural, are safely and efiectively reproduced on the world-famous Garrard four-speed automatic record player' To the Garrardn FISHER has added a stereophonic cartridge equipped with a iliamond LP stylus for long record life and mini mum reeord wear. A separate flip-over stylus is also provided for 78 r.p.m. recordings. This cartridge is of the compatible type, which means that it will play either stereo or rnonaural recordings without requiring any type of adjustment" The ease with which you can utilize the many wonderful features ol the 510 will be readily apparent when you have read the concise, yet complete, instructions on the pages that follow. STEREOPHONIC SOUND In monaural high fidelity systems, tbe reproduced sound has all the characteristics of the original performances - with two exceptions. These are d,irection and, d,isnnce. With the advent of stereophonic high fidelity systems, all the charaeteristics of live sound are now capable of being reproduced in the home or auditotium. THE FISHER 5I4 in conjunction with the Stereo Cornpanion, constitutes a complete stereophonic system. Reproduetion of the live sound characteristics of direction and distance are made pos- eible by the use of trto sound sources and. two sound channels. For example, two micro- phones are placed before an orchestra so that they "hear" the music as we would, with both ears. What is picked up by each microphone is then recorded separately and in- dependently on reeord or tape, or broadcast as a stereo radio program. The stereo pro' gram is then reproduced through two separate sound channels. The sound originally picked up by the microphone on the left is used to drive a speaker system on your left, while the souud picked up by the microphone on the right simultaneously drives a speaker system placed on your right. The efiectiveness of high fidelity stereophonic sound in achieving realism is much greater than might be imagined on the basis of the simple explanation just given. The stereo system actually spreads out the orchestral sound in the same manner as it would emanate from a stage. In other words, instruments located at center stage are heard at a point mid'way between the speakers. The other orchestral instruments can be located accordingly from left to right. This results in a realism and clarity never belore possible in high fidelity systems. The {ollowing stereophonic program sources are already in use, or will be available in the very near future: FM-AM' FM'FM, and FM Multiplex radio broadcasts; com- mercial and home tape recordings; commercial disc recordings. THE FISHER is equipped to handle all these sources, in addition to all standard monaural programs.
