Fender guitars and basses 2003 manual

Page 2

CONTENTS

10
10
19

10

ll

20

Active Electronics
Bass Boost / Cut
MIdrange Boost I Cut
Treble Boost / Cut
Mldrange Boost

Adjustable Pickups
Battery
Care of Your Guitar or Bass

Non-Tremolo Bridges
American Series
Standard
Vintage Telecaster
Vintage Hard-tail

TBX
Delta -Tone

Switches
Coil Splitter
Dual Coil Selector
Pickup Selector
Series Parallel

Tone Controls
Standard

Tremolo Systems
American Series
Deluxe American Series
Fender Deluxe Locking
Floyd Rose!
Vintage Synchronized Tremolo

Truss Rod
Bi-Flex Truss Rod
Standard Truss Rod

Truss Rod, Action, and intonation Adjustments
American Series
Bi-Flex Truss Rod
Fender Deluxe Locking
Floyd Rose!
Standard Truss Rod
Vintage

Tuning Gears
Adjustable
Locking

Volume
Warranty

Thank You

We are pleased that you have selected one of our fine quality
instruments. Fender guitars and basses combine the highest
quality components with the finest workmanship and are
warranted to give you complete satisfaction. This
instrument contains many features and new improvements
developed by our engineers.

As a result, you are assured of receiving an instrument of
superior quality, lasting beauty, and exceptional playability.
We urge you to take the time to read this manual and familiarize
yourself with the many new features and capabilities of this
instrument.

PLEASE NOTE: The accessory kit Included with your Instrument is a multi
purpose kit containing components for several different instrument series'.
Therefore, you may find one or more superfluous components in this kit that
do not have an application for adjusting your specific guitar or bass.

FEATURES AND SPECIFICATIONS FOR YOUR SPECIFIC INSTRUMENT

For detailed Information on the features and specifications of your instrument,
visit the Fender website at www.fender.com. For switching/control function and
wiring diagrams for your specific instrument, visit our customer service
website at www.mrgearhead.com. You may also contact Fender directly for
this information either by mail, telephone or e-mail at:

Attn: Consumer Relations Dept.
Fender Musical instruments Corp.
8860 East Chaparral Rd. Suite 100
Scottsdale, AZ 85250-2618

Phone: 480-596-9690

E-Mail: custservefiifenderusaxom
