Electro harmonix soul preacher owner manual

Page 1

- CONTROLS - Status LED – When the effect is engaged this red LED will illuminate. While the Soul Preacher is in True Bypass, the Status LED will be off. Press the footswitch to toggle between effect and true bypass mode. When the power is applied, the Status LED should glow bright ly signaling all operational voltages are satisfactory. VOL – use to adjust the amount of make-up gain. SUSTAIN – use to set the amount of compression ATTACK– sets the timing of the attack / decay -POWER- Power from the internal 9-volt battery is activated by plugging into the INPUT jack. The input cable should be removed when the unit is not in use to avoid running down the battery. If a battery eliminator is used, the Soul Preacher will be powered up as long as a wall-wart is plugged into the wall. Please make sure to use Alkaline or Lithium high e nergy Batteries with this pedal. The correct, optional 9V power supply from Electro-Harmonix is t he US9.6VDC- 200BI (same as used by Boss™ & Ibanez™9.6 Volts DC 200mA ). The battery eliminator must have a barrel connector with center negative. The battery may be left in or taken out when using an eliminator. - WARRANTY INFORMATION - Please register online at http://www.ehx.com/produc t-registration or complete and return the enclosed warranty card within 10 days of purchase. Electro-Harmonix will repair or replace, at its discretion, a product tha t fails to operate due to defects in materials or workmanship for a period of one year f rom date of purchase. This applies only to original purchasers who have bought their product from an authorized Electro-Harmonix retailer. Repaired or replaced uni ts will then be warranted for the unexpired portion of the original warranty term. If you should need to return your unit for service within the warranty period, please contact the appropriate office listed below. Custom ers outside the regions listed below, please contact EHX Customer Service for info rmation on warranty repairs at info@ehx.com or +1-718-937-8300. USA and Canadian c ustomers: please obtain a Return Authorization Number (RA#) from EHX Customer Service before returning your product. Include with your returned unit: a w ritten description of the problem as well as your name, address, telephone number, e- mail address, and RA#; and a copy of your receipt clearly showing the purchase d ate. United States & Canada EHX CUSTOMER SERVICE ELECTRO-HARMONIX c/o NEW SENSOR CORP. 55-01 2ND STREET LONG ISLAND CITY, NY 11101 Tel: 718-937-8300 Email: info@ehx.com Europe JOHN WILLIAMS ELECTRO-HARMONIX UK 13 CWMDONKIN TERRACE SWANSEA SA2 0RQ UNITED KINGDOM Tel: +44 179 247 3258 Email: electroharmonixuk@virginmedia.com This warranty gives a purchaser specific legal righ ts. A purchaser may have even greater rights depending upon the laws of the juris diction within which the product was purchased. To hear demos on all EHX pedals visit us on the web at www.ehx.com Email us at info@ehx.com
