Extracted text from Dual XD 622W Owners Manual (Ocr-read)
Page 1
2 XD622WINSTALLATION Preparation SECURITY LED Please read entire manual before installation. Before You Start -Disconnect negative battery terminal. (consult a qualified technician for instructions) -A void installing the unit where it would be subject to high temperatures, such as from direct sunlight, or where it would be subject to dust, dirt or excessive vibration. Getting Started - Remove 2 transit screws located on top of the unit. - Insert the supplied keys into the slots as shown, and slide the unit out of the mounting sleeve. - Install mounting sleeve into opening, bending tabs to secure. - Connect wiring harness and antenna. (consult a qualified technician if you are unsure) - Certain vehicles may require an installation kit and/or wiring harness adapter (sold separately). -T est for correct operation and slide into mounting sleeve to secure. - Snap trim ring into place. TYPICAL MOUNTING METHOD
Page 2
FUSE When replacing a fuse, make sure new fuse is the correct type and amperage. Using an incorrect fuse could damage the radio. The XD622W uses one 10 amp ATM fuse located beside the wiring connector. 3 XD622WINSTALLATION Wiring Diagram
Page 3
4 XD622WOPERATION Control Locations Release Power Audio Scan Display Auto Store/Preset Scan EQ Tune/Track Down Eject Tune/Track Up 1 2 3 4 5 6 7 8 9 10 Mode Bass Boost Preset 6 Preset 5 Preset 4 Preset 3/CD Intro Preset 2/CD Random Preset 1/CD Repeat Play/Pause/Band Mute 11 12 13 14 15 16 17 18 19 20 20 19 18 17 16 15 14 13 12 11 1 2 3 4 5 6 7 8 9 10 For semi-permanent faceplate installation, remove trim ring and install supplied Phillips head #1 screw through left side of mounting frame into faceplate. *Semi-permanent Faceplate Attachment
