Dual DMS 692 Owners Manual
This is the 8 pages manual for Dual DMS 692 Owners Manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from Dual DMS 692 Owners Manual (Ocr-read)
Page 1
2 DMS SERIESPREPARATION Getting Started Safety This symbol with CAUTION is intended to alert the user to the presence of important instructions. Failure to heed the instructions can result in injury or unit damage. To prevent injury and damage to the unit, please read and follow the instructions in this manual. If you feel unsure about installing this system yourself, have it installed by a qualified audio technician. Before installation, disconnect the battery negative (-) terminal to prevent damage to the unit, fire and/or possible injury. Thanks for choosing Dual. This manual is designed to provide information for the purchaser of Dual Marine products. Dual has attempted to make sure all the information in this manual is current. But, this information is subject to change without notice.
Page 2
3 DMS SERIESINSTALLATION Installation Please Note: This manual covers multiple models. Parts of the following instructions may not apply to your installation. The installation instructions included here are basic. If you feel unsure about personally installing the speaker system. Dual recommends that you seek installation by a qualified sound technician. Before installation, please follow the following rules: 1. Be sure to carefully read and understand the instructions beforeattempting to install the product. 2. For safety, disconnect the negative lead from the battery prior to beginning the installation. 3. For easier assembly, we recommend that if additional wiring is required, that you run all wires prior to mounting your speaker in place. 4. Use the highest quality connectors for a reliable installation and to minimize signal or power loss. 5. Use caution before you drill or cut! Be careful not to cut or drill into gas tanks, fuel lines, hydraulic lines, vacuum lines or electrical wiring when working on any vessel. 6. Never run speaker wires underneath or on the exgterior of your vessel. Running speaker wires inside provides the best protection from environmental elements. 7. Avoid running wires over, near, or through sharp edged surfaces. We suggest you also use rubber grommets to protect any wires routed through metal or fiberglass. 8. When running the speaker cable from the receiver or amplifier, avoid running it near sources of high current (i.e. wiring harnesses, battery cables). 9. The positive (+) speaker output from the receiver or amp connects to the red terminal of the enclosure, and the negative (-) connects to the black terminal.
Page 3
4 DMS SERIESSPECIFICATIONS Features & Specifications DMS692 6 X 9 COAXIAL MARINE SPEAKER - Magnetically Shielded - Santopren rubber surround - UV impregnated ABS heat-resistant weatherproof grilles - One-piece cast ABS basket - Recommended amplifier power 10-80 watts RMS, 200 watts Peak - Requires 3.82" of mounting depth and 5.75x8.80 cutout Sensitivity: 94dB Frequency Response: 55Hz – 22 kHz Tweeter: 25 mm Dome Ferrofluid Neo Woofer: 6x9 Poly - 20 oz Magnet with 2 Layer Voice Coil Impedance: 4 ohm nominal Dimensions: Diameter 7.75x10 Note: All specifications are subject to change without notice. DMS655SM 6.5 SURFACE MOUNT MARINE SPEAKER - Magnetically Shielded -Santopren rubber surround -UV impregnated ABS heat-resistant weatherproof enclosure and Grille - One-piece cast ABS basket - Recommended amplifier power 10-65 watts RMS, 175 watts Peak - Easily converts from surface mount to flush mount Sensitivity: 93dB Frequency Response: 60 Hz – 20 kHz Tweeter: 19 mm Silk Dome Ferrofluid Neo Woofer: 6.5 Poly - 11 oz Magnet with 2 Layer Voice Coil Impedance: 4 ohm nominal Dimensions: Enclosure (HxWxD) 7.5x7.25x5.13
