Dual DC 525BI Owners Manual
This is the 30 pages manual for Dual DC 525BI Owners Manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from Dual DC 525BI Owners Manual (Ocr-read)
Page 1
2 DC525Bi INSTALLATION Preparation Please read entire manual before installation. Before You Start - Disconnect negative battery terminal. Consult a qualified technician for instructions. - Avoid installing the unit where it would be subject to high temperatures, such as from direct sunlight, or where it would be subject to dust, dirt or excessive vibration. Getting Started - Remove trim ring from unit. - Remove 2 transit screws located on top of the unit. - Insert the supplied keys into the slots as shown, and slide the unit out of the mounting sleeve. - Install mounting sleeve into opening, bending tabs to secure. - Connect wiring harness and antenna. Consult a qualified technician if you are unsure. - Certain vehicles may require an installation kit and/or wiring harness adapter (sold separately). - Test for correct operation and slide into mounting sleeve to secure. - Snap trim ring into place. TYPICAL FRONT-LOAD MOUNTING METHOD
Page 2
3 DC525Bi INSTALLATION Wiring Diagram FUSE When replacing the fuse, make sure new fuse is the correct type and amperage. Using an incorrect fuse could damage the radio. The DC525Bi uses one 10 amp ATM fuse located beside the wiring connector. 10 AMP AGC Fuse Antenna Connector
Page 9
10 DC525Bi OPERATION CD Player Operation - MP3/WMA Files Playing an MP3/WMA Disc Displaying Information Title Icon Artist Icon Folder Icon File Icon Character SupportWhen an MP3/WMA encoded disc is first inserted, DISC READ will appear in the display. Depending on the number of files and folders, this may take several seconds. Press DISP to select between song title, artist, file name, folder name, track number, and clock/elapsed time. NO ARTIST or "NO TITLE" will be displayed if the MP3/ WMA file contains no ID3 tag information. ROOT will be displayed if the directory name of a root folder is not labeled. This icon will illuminate when the song title is displayed. This icon will illuminate when the artist name is displayed. This icon will illuminate when the folder name is displayed. This icon will illuminate when the file name is displayed. Maximum character display information - Track name – 32 character maximum - Directory name – 32 character maximum - *Song title – 32 character maximum - *Artist name – 32 character maximum *Song title and Artist Name will only be displayed if included with the MP3/WMA file. When referring to MP3/WMA playback, the following terms are synonymous: - File name and track name - Folder name and directory name
Page 20
21 DC525Bi OPERATION - iPod touch (6th generation) - iPod nano (6th generation) - iPod touch (5th generation) - iPod nano (5th generation) - iPod touch (4th generation) - iPod nano (4th generation) - iPod touch (3rd generation) - iPod nano (3rd generation) - iPod touch (2nd generation) - iPod nano (2nd generation) - iPod classic - iPod touch (1st generation) - *iPod nano (1st generation) - *iPod with video - iPhone 5S - iPhone 5 - iPhone 4S - iPhone 4 - iPhone 3GS - iPhone 3G - iPhone *These devices are not compatible with 'basic' control mode. Made for Device Compatibility Operation of iPod/iPhone
Page 24
25 DC525Bi OPERATION The DC525Bi supports A2DP (advanced audio distribution profile) wireless streaming audio from your Bluetooth mobile device directly to your head unit. You can also control your music from the front panel of the head unit using AVRCP (audio video remote control profile). Notes: - To stream music to your head unit, your mobile device must support the A2DP and AVRCP Bluetooth profiles. Check the owner's manual of your mobile device for details. - Streaming audio must be enabled from your mobile device. This option will vary depending on the device. Some devices allow streaming audio to be disabled. After pairing, connecting and enabling streaming audio from a compatible mobile device, begin playing music using the music player on your mobile device. Once the music is playing, the following functions can be used to control the music: - The ll button will skip to the next available audio track. - The nn button will skip to the previous audio track. - The l/ II button will toggle between play and pause during playback. - The button will stop the audio playback. Note: Some Bluetooth devices may not fully support these commands. Streaming Audio Operation Bluetooth ® Operation
Page 26
27 DC525Bi OPERATION Specifications Frequency response: 10Hz-20kHz Channel separation @ 1kHz: >65dB D/A converter: 1 Bit Tuning range: 87.5MHz-107.9MHz Usable sensitivity: 8.5dBf 50dB quieting sensitivity: 10dBf Stereo separation @ 1kHz: 40dB Frequency response: 30Hz-13kHz Tuning range: 530kHz-1710kHz Usable sensitivity: 22uV Frequency response: 30Hz-2.2kHz Speaker output impedance: 4~8 ohms Line output voltage: 2 Volts RMS Dimensions: 4" x 7" x 7" (51 x 178 x 178 mm) Design and specifications subject to change without notice. CD Player FM Tuner AM Tuner General CEA-2006 Power Standard Specifications (reference: 14.4VDC +/- 0.2V, 20Hz~20kHz) Power Output: 18 Watts RMS x 4 channels at 4 ohms and < 1% THD+N Signal to Noise Ratio: 80dBA (reference: 1 watt into 4 ohms)
