Dual BP 1204 Owners Manual
This is the 8 pages manual for Dual BP 1204 Owners Manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from Dual BP 1204 Owners Manual (Ocr-read)
Page 1
BP1204 PREPARATION Getting Started Thank you for purchasing the Dual Electronics BP104 Bandpass Subwoofer System. Although Dual has attempted to ensure the information in this ma\ nual is accurate, please be aware that any part of it is subject to change witho\ ut notice. Safety CA UTION ! THE FOLLOWING INSTRUCTIONS ARE DESIGNED TO ENSURE SAFETY DURING INSTALLATION AND USE OF THE BP104. FAILURE TO HEED THESE INSTRUCTIONS CAN RESULT IN INJURY OR DAMAGE TO THE UNIT. - To prevent injury and damage to the unit, please read and follow the instructions in this manual. - If you feel unsure about installing this system yourself, have it instal\ led by a qualified audio technician. - Before installation, disconnect the battery negative (-) terminal to p\ revent damage to the unit, fire and/or possible injury. - Do not connect amplifier or any audio source to illumination inputs. T\ hese inputs are designed for 1 volt power only. - Illuminite inputs are designed for 1 volt DC power source only. Do NOT connect your illuminite product directly to your battery permanently, as\ it will cause your battery to discharge. Please use a switched 1 volt source.
Page 2
BP1204 INSTALLATION Installation The following installation instructions are very basic. If you feel unsu\ re about installing this speaker system yourself, Dual recommends aquiring the se\ rvices of a professional car audio installation center. Before installation, please review the following guidelines: 1. Be sure to carefully read and understand the instructions before attempting to install this product. . For safety, disconnect the battery negative terminal prior to beginning the installation. . If additional wiring is required, we recommend running all wires prior t\ o mounting your speaker in place. 4. To ensure reliable performance and minimize signal or power loss, use th\ e highest quality connectors available. 5. Use caution before you drill or cut! Be careful not to cut or drill into\ gas tanks, fuel lines, brake or hydraulic lines, vacuum lines or electrical wiring when working on any vehicle. 6. Never run speaker wires underneath your vehicle. Running speaker wires inside the vehicle provides the best protection from exhaust, heat and environmental elements. 7. Avoid running wires over, near or through sharp-edged surfaces. We suggest you also use rubber grommets to protect any wires routed through metal, especially the firewall. 8. When running the speaker cable from the amplifier, avoid running it ne\ ar sources of high current (i.e. wiring harnesses, battery cables). 9. When connecting the amp, the positive (+) speaker output from the bass\ amp connects to the positive (+) terminal and the negative output (-) co\ nnects to the negative (-) input terminal on the input cup located on the rea\ r of the subwoofer enclosure. DO NOT CONNECT AMP OR ANY AUDIO SOURCE TO ILLUMINATION INPUTS, AS DAMAGE TO LIGHTS WILL OCCUR. 10. For the illumination connection, the positive (+) output from your\ 1V system connects to the positive (+) input and the negative (ground) connect\ s to the negative (-) input on the input cup located on the rear of the sub\ woofer enclosure. Improper 1V polarity will not cause damage to the lights, but they will not illuminate.
