Digitech rp 12
This is the 85 pages manual for digitech rp 12.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from digitech rp 12 (Ocr-read)
Page 1
DECLARATION OF CONFORMITY ManufacturerÕs Name: Digitech ManufacturerÕs Address: 8760 S. Sandy Parkway Sandy, Utah 84070, USA declares that the product: Product Name: RP-12 Product Options: All (requires a Class II power adapter that conforms to the require- ments of EN6005, EN60742, or equivalent). conform to the following Product Specifications: Safety: EN 60065 (1993) IEC 65 (1987) with Amendments 1, 2 & 3 EMC: EN 55013 (1990) EN 55020 (1991) Supplementary Information: The product herewith complies with the requirements of the Low Voltage Directive 73/23/EEC and EMC Directive 89/336/EEC as amended by Directive 93/68/EEC. . Digitech President of Digitech 8760 S. Sandy Parkway Sandy, Utah 84070, USA Effective October 17, 1996 European Contact: Your Local DigiTech Sales and Service Office or International Sales Office 3 Overlook Drive #4 Amherst, New Hampshire 03031, USA Tel (603) 672-4244 Fax (603) 672-4246 RP-12 OwnerÕs Manual
Page 2
1 Table Of Contents . . . . . . . . . . . . . . . . . . . . . . . . . . 1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . 4 Lithium Battery Warning . . . . . . . . . . . . . . . . . . 5 Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Section 1 - Startup Supplying power . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Line Conditioning . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Front Panel Controls . . . . . . . . . . . . . . . . . . . . . . . . 7 Pedalboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Display Window . . . . . . . . . . . . . . . . . . . . . . . . 8 Program Buttons . . . . . . . . . . . . . . . . . . . . . . . . 8 Parameter Buttons . . . . . . . . . . . . . . . . . . . . . . 8 Effect Library Buttons . . . . . . . . . . . . . . . . . . . . 8 Global Buttons . . . . . . . . . . . . . . . . . . . . . . . . . 8 Main Output Level. . . . . . . . . . . . . . . . . . . . . . . 9 Continuous Control Pedal . . . . . . . . . . . . . . . . . 9 Rear Panel Connections . . . . . . . . . . . . . . . . . . . . . 9 Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Right Output . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Left/Mono Output . . . . . . . . . . . . . . . . . . . . . . . 9 Headphone Output . . . . . . . . . . . . . . . . . . . . . . 9 AC Line Input . . . . . . . . . . . . . . . . . . . . . . . . . . 9 MIDI In . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 MIDI Out / Thru. . . . . . . . . . . . . . . . . . . . . . . . . 9 MIDI and Audio Setups . . . . . . . . . . . . . . . . . . . 10 Section 2 - Basic Operations Program Architecture . . . . . . . . . . . . . . . . . . . . . . . . 12 Tuning with the RP-12 . . . . . . . . . . . . . . . . . . . . . . . 13 Changing the Tuning Reference . . . . . . . . . . . . . . . 14 Assigning Programs to Footswitches . . . . . . . . . . . . 14 Assigning Parameters to Footswitches . . . . . . . . . . . 15 Section 3 - Programming Using the Function Keys . . . . . . . . . . . . . . . . . . . . . 16 More Special Characters . . . . . . . . . . . . . . . . . . . . . 16 The Effects Library Buttons . . . . . . . . . . . . . . . . . . . 17 About the I / O Module. . . . . . . . . . . . . . . . . . . . . . . 17 Modifying Factory Programs . . . . . . . . . . . . . . . . . . 17 Basic Program Creation . . . . . . . . . . . . . . . . . . . . . . 18 Selecting an Algorithm . . . . . . . . . . . . . . . . . . . 18 Naming Programs . . . . . . . . . . . . . . . . . . . . . . . 19 Storing Programs . . . . . . . . . . . . . . . . . . . . . . . 19 Section 4 - Effects and Parameters About the Effects Library . . . . . . . . . . . . . . . . . . . . . 22 Analog Effects . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 Compressor . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 Distortion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 Equalizers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23 Cabinet Emulator . . . . . . . . . . . . . . . . . . . . . . . 24 Reverbs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 Gated Reverbs . . . . . . . . . . . . . . . . . . . . . . . . . 29 RP-12 OwnerÕs Manual Table of Contents
