Main Specifi cations: Power amplifi er section Rated output *THD fi gures are power amp stage values. Front L/R 80 W + 80 W (8 ohms, 20Hz - 20kHz, THD 0.08 %) 110 W + 110 W (6 ohms, 1 kHz, THD 0.7%) Center 80 W (8 ohms, 20Hz - 20kHz, THD 0.08 %) 110 W (6 ohms, 1 kHz, THD 0.7%) Surround L/R 80 W + 80 W (8 ohms, 20Hz - 20kHz, THD 0.08 %) 110 W + 110 W (6 ohms, 1 kHz, THD 0.7%) Surround Back L/R 80 W + 80 W (8 ohms, 20Hz - 20kHz, THD 0.08 %) 110 W + 110 W (6 ohms, 1 kHz, THD 0.7%) 1741 0608 A Denon Brand CompanyD&M Building, 2-1 Nisshin-cho, Kawasaki-ku, Kawasaki-shi, Kanagawa, 210-8569, Japan www.denon.com Denon Electronics (USA), LLC.100 Corporate Drive, Mahwah, New Jersey 07430 USA TEL: 201-762-6500 usa.denon.com Denon Canada Inc.505 Apple Creek Blvd, Unit 5, Markham, Ontario, Canada L3R 5B1 TEL: 905-475-4085 ca.denon.com *Design and specifi cations are subject to change without notice. *Dolby, Pro Logic and the double-D symbol are trademarks\ of Dolby Laboratories. *DTS, DTS Digital Surround, ES, and Neo:6 are registered trademarks and the DTS logos, Symbol and DTS 96/24 are trademarks of DTS, Inc. *Audyssey MultEQ ® is a registered trademark of Audyssey Laboratories. Audyssey Dynamic EQ™ is a trademark of Audyssey Laboratories. Audyssey Dynamic Volume ™ is a trademark of Audyssey Laboratories. *HDMI, HDMI logo and High-Definition Multimedia Inte\ rface are trademarks or registered trademarks of HDMI Licensing LLC. *iPod ® is a trademark of Apple Inc., registered in the U.S. and other countries. *x.v.Color is trademark of Sony Corporation. State-of-the-art Denon Solutions for Maximizing Content Quality - Robust power source for each block, for stable supply of current To produce a clear, stable power circuit that prevents unwanted noise from aff ecting the sound, the AVR-1709 has a dedicated CPU transformer that are separate from the audio and video circuitry. The AVR-1709 is endowed with a powerful rectifi er circuit with 10,000μF block capacitors and a bridge diode of 8A capacity, surpassing typical models in this price range, to supply stable current with negligible noise. - Minimum Signal Path The "simple and straight" design concept has been thoroughly implemented in the signal paths to contribute to immaculately clean audio and video playback. Signal paths are as short as possible to keep signal degradation in the audio and video circuitry to an absolute minimum. - Direct Mechanical Ground Vibration-resistant construction has been reviewed to thoroughly suppress the adverse infl uences of vibration on sound quality. The power transformers, a source of vibration, have been securely mounted on the highly rigid bottom chassis. Direct mounting of cast-iron feet to the radiator in near proximity to each other serves to suppress mutual vibration with the power transformers and other sources of vibration. - Compressed Audio Restorer Denons new audio technology for MP3/WMA/AAC compressed audio formats restores higher frequency sounds, along with rich, deeper bass. Connectivity & Future-ready Expandability - Includes dedicated zone remote control unit - Power amplifi er assign for zone 2 - Remote in/out Ease-of-Use - Audyssey Dynamic Volume, for real-time volume adjustment Large changes in volume sometimes occur between docu- mentaries where the sound is mainly narrative and movies which often contain loud sound eff ects. Viewers often raise the volume for documentaries to hear the narrative more easily but then turn it down again when a commercial with loud sound eff ects comes on. They do this numerous times during a program of this type. Audyssey Dynamic Volume constantly monitors the sound sources and adjusts the volume to the optimum level for the particular source being heard without sacrifi cing dynamic range. The AVR-1709 is also equipped with Audyssey MultEQ which measures the acoustic characteristics of the room to obtain the optimum acoustic eff ects, and Dynamic EQ which reproduces the high and low range with the optimum acoustic eff ect during low volume levels. Dynamic Volume combines these two func- tions to achieve maximum performance. - MultEQ Auto setup and Room EQ -Tower type microphone for more accurate measuring -Up to six measurement points -High level resolution fi lters for satellite speakers and also subwoofer - Three Quick Select Buttons - Auto setup, auto surround, auto signal detection - Auto Surround Back Channels on for auto-detection of supporting sources - Auto Surround mode - Audio Delay function (max. 6 frames or 200 msec) - Night Mode for neighbor friendly listening - Muting level settings (Full/-40dB/-20dB) - Audio Level Memory, capable of correcting diff erent signal levels for each input device - Volume Level Limiter, for setting maximum volume levels - Power-ON Volume Level Memory - Variable subwoofer crossover switching Input / Output Terminals: IN HDMI 3 Component 3 S-Video 3 Composite 4 Analog Audio (Tuner included) 7 Analog EXT. Input 7.1ch Digital OPTICAL 2 Digital COAXIAL 2 OUT HDMI Monitor 1 Component Monitor 1 S-Video Monitor 1 REC 1 Composite Monitor 1 REC 1 Analog Audio REC 2 Zone 2 1 Audio PRE out (Sub woofer) 1 Others Dock Control Port 1 Sirius Connector 1 FM Tuner Antenna 1 AM Tuner Antenna 1 Remote In/Out 1 Preamplifi er section Input sensitivity/impedance 200 mV / 47 kΩ/kohms Frequency response10 Hz ~ 100 kHz - +1, –3 dB (DIRECT mode) S/N Ratio 98 dB (IHF-A weighted, DIRECT mode) FM section Tuning frequency range 87.5 - 107.9 MHz Usable sensitivity 1.0 μV (11.2 dBf) AM section Tuning frequency range 520 - 1710 kHz Usable sensitivity 18 μV General Power supply AC 120 V, 60 Hz Power consumption 4.6 A (Standby 0.3W) Dimensions (W x H x D) 434 x 171 x 377 mm 17-3/32 x 6-47/64 x 14-27/32 Weight 11.3 kg 24lbs 14.6oz
