Dbx 640 641 Owners Manual
This is the 59 pages manual for Dbx 640 641 Owners Manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from Dbx 640 641 Owners Manual (Ocr-read)
Page 1
WARNING FOR YOUR PROTECTION READ THE FOLLOWING: KEEP THESE INSTRUCTIONS HEED ALL W ARNINGS FOLLOW ALL INSTRUCTIONS DO NOT USE THIS APP ARATUS NEAR W ATER CLEAN ONL Y WITH A DR Y CLOTH. DO NOT BLOCK ANY OF THE VENTILA TION OPENINGS. INST ALL IN ACCORDANCE WITH THE MANUF ACTURERS INSTRUCTIONS. DO NOT INST ALL NEAR ANY HEA T SOURCES SUCH AS RADIA TORS, HEA T REGISTERS, STOVES, OR OTHER APP ARATUS (INCLUDING AMPLIFIERS) THA T PRODUCE HEA T. ONLY USE A TTACHMENTS/ACCESSORIES SPECIFIED BY THE MANUF ACTURER. UNPLUG THIS APP ARATUS DURING LIGHTNING STORMS OR WHEN UNUSED FOR LONG PERIODS OF TIME. Do not defeat the safety purpose of the polarized or grounding-type plug\ . A polar - ized plug has two blades with one wider than the other . A grounding type plug has two blades and a third grounding prong. The wide blade or third prong a\ re pro - vided for your safety . If the provided plug does not fit your outlet, consult an elec - trician for replacement of the obsolete outlet. Protect the power cord from being walked on or pinched particularly at p\ lugs, con - venience receptacles, and the point where they exit from the apparatus. Use only with the cart stand, tripod bracket, or table specified by the \ manufacture,or sold with the apparatus. When a cart is used, use caution when movin\ g thecart/apparatus combination to avoid injury from tip-over . Refer all servicing to to qualified service personnel. Servicing is req\ uired whenthe apparatus has been damaged in any way , such as power -supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparat\ us, the appa - ratus has been exposed to rain or moisture, does not operate normally , or has been dropped. POWER ON/OFF SWITCH: For products provided with a power switch, the powe\ r switch DOES NOT break the connection from the mains. MAINS DISCONNECT: The plug shall remain readily operable. For rack-mount or installation where plug is not accessible, an all-pole mains switch with\ a contact separation of at least 3 mm in each pole shall be incorporated into the \ electrical installation of the rack or building. FOR UNITS EQUIPPED WITH EXTERNALLY ACCESSIBLE FUSE RECEPTACLE: Replace fuse with same type and rating only. MULTIPLE-INPUT VOLTAGE: This equipment may require the use of a different line cord, attachment plug, or both, depending on the available power source \ at instal- lation. Connect this equipment only to the power source indicated on the\ equipment rear panel. To reduce the risk of fire or electric shock, refer servicing to qualifie\ d service personnel or equivalent. This Equipment is intended for rack mount use only. SAFETY INSTR UCTIONS NOTICE FOR CUSTOMERS IF YOUR UNIT IS EQUIPPED WITH A POWER CORD. WARNING: THIS APPLIANCE MUST BE EARTHED. CONNECT ONLY TO A MAINS SOCKET OUTLET WITH PROTECTIVE EARTHING CONNECTION. The cores in the mains lead are coloured in accordance with the following code: GREEN and YELLOW - Earth BLUE - Neutral BROWN - Live As colours of the cores in the mains lead of this appliance may not correspond with the coloured markings identifying the ter- minals in your plug, proceed as follows: - The core which is coloured green and yellow must be con- nected to the terminal in the plug marked with the letter E, or with the earth symbol, or coloured green, or green and yellow. - The core which is coloured blue must be connected to the terminal marked N or coloured black. - The core which is coloured brown must be connected to the terminal marked L or coloured red. This equipment may require the use of a different line cord, attachment plug, or both, depending on the available power source at installation. If the attachment plug needs to be changed, refer servicing to qualified service personnel who should refer to the table below. The green/yellow wire shall be connected directly to the units chassis. W ARNING: If the ground is defeated, certain fault conditions in the unit or in the system to which it is connected can result in full line voltage between chassis and earth ground. Severe injury or death can then result if the chassis and earth ground are touched simultaneously. LIVE E NEUTRAL EARTH GND CONDUCTOR L N BROWN BLUE GREEN/YEL BLACK Normal Alt WIRE COLOR WHITE GREEN The symbols shown above are internationally accepted symbols that warn of potential hazards with electrical products. The lightning flash with arrowpoint in an equi- lateral triangle means that there are dangerous voltages present within the unit. The exclamation point in an equi- lateral triangle indicates that it is necessary for the user to re fer to the owners manual. These symbols warn that there are no user serviceable parts inside the unit. Do not open the unit. Do not attempt to service the unit yourself. Refer all servicing to qualified personnel. Opening the chassis for any reason will void the manufacturers warranty. Do not get the unit w et. If liquid is spilled on the unit, shut it off immediately and take it to a dealer for service. Disconnect the unit during storms to prevent damage. CAUTION ATTENTION: RISQUE DE CHOC ELECTRIQUE - NE PAS OUVRIR WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK DO NOT EXPOSE THIS EQUIPMENT TO RAIN OR MOISTURE RISK OF ELECTRIC SHOCK DO NOT OPEN IMPORTANT SAFETY INSTRUCTIONS
Page 2
U.K. MAINS PLUG W ARNING A molded mains plug that has been cut off from the cord is unsafe. Discard the mains plug at a suitable disposal facility. NEVER UNDER ANY CIRCUMSTANCES SHOULD YOU INSERT A DAMAGED OR CUT MAINS PLUG INTO A 13 AMP POWER SOCKET. Do not use the mains plug without the fuse cover in place. Replacement fuse covers can be obtained from your local retailer. Replacement fuses are 13 amps and MUST be ASTA approved to BS1362. IMPORTANT SAFETY INSTRUCTIONS ELECTROMAGNETIC COMP ATIBILITY This unit conforms to the Product Specifications noted on the Declaration of Conformity .Operation is subject to the following two conditions: - this device may not cause harmfulinterference, and - this device must accept any interfer- ence received, including interference that may cause undesired operation. Operation of this unit within significant electromagnetic fields should be avoided. - use only shielded interconnecting cables. DECLARATION OF CONFORMITY Manufacturers Name: dbx Professional Products Manufacturers Address: 8760 S. Sandy Parkway Sandy, Utah 84070, USA declares that the product: Product name: dbx 640 and dbx 641 Note: Product name may be suffixed by the letters-EU. Product option: None conforms to the following Product Specifications: Safety: IEC 60065 (1998) EMC: EN 55013 (1990) EN 55020 (1991) Supplementary Information: The product herewith complies with the requirements of the Low Voltage Directive 72/23/EEC and the EMC Directive 89/336/EEC as amended by Directive 93/68/EEC. Vice-President of Engineering 8760 S. Sandy Parkway Sandy, Utah 84070, USA Date: February 6, 2004 European Contact: Your local dbx Sales and Service Office or Harman Music Group 8760 South Sandy Parkway Sandy, Utah 84070 USA Ph: (801) 566-8800 Fax: (801) 568-7583
