crumar stratus service manual

Extracted text from crumar stratus service manual (Ocr-read)

Page 2

FEMALE CONNECTOR SYMBOL (es.J 2/1)
PLUG IN CONNECTOR SYMBOL

WIRE SOlDERING POINT

TEST POINT (T P...)

CONNECTING POINTION p.c.b.)
METALLIC FILM RESISTOR 17.

D-0032

ALLresistors1/4w unless otherWIse indicated
ALLtabswitches shown inOFF position
ALLkeyswitches shown in OFF position

Seepart list for component part numbers

CHIIMAII RESERVES THE RIGHT TO CHANGE
SPECIFICATIONS AND IIESIBNS. WITNIJIIT
NOTICE AND llABllITY.
