The OBH-8 and OBH-9 use dedicated circuitry to optimise their performance and cannot be switched from MM to MC. The level output from both the OBH-8 and 9 is suitable for most line level amplifiers and the input sensitivity and loading is factory-set to suit a wide range of cartridges. OBH-8SE There is now an Audiophile version of the OBH-8 known as the Special Edition, which uses audio grade and closer tolerance components, with specific circuitry added to enhance its performance. The SE gain stage uses a cascoded low noise J-FET, instead of a sin- gle bi-polar transistor. This enables the input to be DC cou- pled, removing a capacitor from the signal path. Cascoding increases the gain, especially at high frequencies and therefore improves linearity. Signal connectors on the SE are gold plated and the OBH-8SE is supplied with the up-rated, high current OBH-2 power supply. These improvements add up to a more transparent, dynamic and revealing sound, totally lacking in colouration, that will thrill vinyl enthusiasts. Gain 37 dB Frequency Response20 Hz to 20 kHz ± 0.25 dB Signal to Noise Ratio- 82 dB Total Harmonic Distortion< 0.05% R1AA deviation ± 0.5 dB Output 250 mV Output Impedance750 W W Input sensitivity/impedance3.5 mV/ 47 kW W / 220 pF Overload margin22 dB Mates well with cartridges with a 1.5 mV to 5.0 mV output. Dimensions100 x 100 x 65 mm Weight420 g Gain 56 dB Frequency Response20 Hz to 20 kHz ± 0.25 dB Signal to Noise Ratio- 75 dB Total Harmonic Distortion:< 0.05% R1AA deviation ± 0.5% Output 250 mV Output Impedance 750 W W Input sensitivity/impedance0.5 mV/ 1000 W W / 3300 pF Overload margin20 dB Mates well with moving coil cartridges with a 0.5 mV to 1.0 mV output. Dimensions100 x 100 x 65 mm Weight420 g O OB BH H- -8 8S SE E T TE EC CH HN NI IC CA AL L S SP PE EC CI IF FI IC CA AT TI IO ON N O OB BH H- -9 9 T TE EC CH HN NI IC CA AL L S SP PE EC CI IF FI IC CA AT TI IO ON N Creek Audio Limited reserves the right to modify or change the specifications of its products at any time without notice. 2 Bellevue Road, Friern Barnet, London N11 3ER, England Tel: 00 44 + (0)181-361 4133 Fax: 00 44 + (0)181-361 4136 E-mail: mcreek@ibm.net Internet: www.creekaudio.co.uk. Gain 37 dB Frequency Response20 Hz to 20 kHz ± 0.25 dB Signal to Noise Ratio- 86 dB Total Harmonic Distortion < 0.03% R1AA deviation ± 0.5 dB Output 250 mV Output Impedance 750 W W Input sensitivity/impedance3.5 mV/ 47 kW W / 220 pF Overload margin25 dB Mates well with cartridges with a 1.5 mV to 5.0 mV output. Dimensions100 x 100 x 65 mm Weight420 g · · · · · · · · · · · · · · · · · · · · · · · · · · · · · ·\ · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · × × ×
