Extracted text from creek destiny cd owners manual (Ocr-read)
Page 1
Destiny CD PLAYERSPECIFICATION Power requirementsSupplied 220/240-50 Hz or 100/120-60Hz (Selectable by switch on underside of player) Power consumption20 W max 6 W in standby mode Mains filteringMulti-pole bi-directional Power supply3 fully encapsulated PCB toroidal transformers for transport, logic and analogue circuitry Frequency response1 Hz - 20 kHz ±0.25 dB Output level2.0 V RMS at 1 kHz, 0 dB Output impedance50W recommended min load 1 K D to A type24 bit - 192 kHz (> 120 dB) Crystal CS4396 Total harmonic distortion < 0.0008% at 1 kHz, 0 dB THD + Noise> -97dB Dynamic range> 117dB Clock typeTemperature compensated ultra low jitter and phase noise module with re-clocking Number of channels2 via high quality solid RCA gold plated sockets Digital outputRe-clocked optical via TORX and transformer coupled co-axial gold plated RCA socket. Laser typeSemiconductor ALGaAs Wavelength790 nm ± 25 nm Light output (cw)0.18 mW typical TransportDVD loader with ATAPI interface. Firmware upgradeable SoftwareCustom Creek software, running loader, display, remote control and DAC. Upgradeable via plug-in EPROM CaseBuilt with custom Creek extruded panels throughout Weight6 Kg (13.2 lbs) Dimensions (W x H x D) mm430 x 70 x 310 (16.9 x 2.7 x 12.2 inches) Remote controlCustom Creek SRC2 system remote handset Uses RC5 codes MAINS VOLTAGE AND FREQUENCY IS INTERNALLY SET FOR THE COUNTRY OF USE Creek Audio Ltd reserves the right to change or modify the specification of its products without prior warning WARRANTY If within two years of purchase date your Destiny product proves to be defective for any reason other than accident, misuse, neglect, unauthorized modification, or fair wear and tear, Creek Audio Ltd. will, at its discretion, replace the faulty parts without charge for labour or return carriage within the U.K. This warranty is valid only in the U.K. and given in addition to statutory rights. Service enquiries outside the U.K. should be addressed first to the supplying dealer and/or the Creek distributor/importer. Warranties granted in these countries are entirely at the discretion of the distributor.WPage Two
Page 2
Destiny CD PlayerEXPLANATION OF CONTROLSFRONT PANEL Skip Skip Play Stop Back Forward Disc Open/ Display Tray Close Pause Window Repeat Display StandbyREAR PANELAC Mains Input Power On/Off R Audio L Digital Creek & Mains Fuse Switch Outputs Outputs LinkAUDIO OUTPUT Connect one end of the interconnect cable to the CD Players audio output sockets and the other end to the sockets labelled CD or AUX or to other line inputs on the amplifier. Do NOT connect it to the amplifiers PHONO input if a phono circuit is installed. DIGITAL OUTPUT This output enables you to connect the CD player to a stand-alone D to A converter in order to change the signal into stereo analogue. The digitial output can be accessed via the co-axial SPDIF or optical Toslink socket on the rear panel CREEK LINK When development of Creeks separate interface is completed, it will enable you to connect to a custom room controller and operate your system from another part of the house.DISPLAY WINDOW A B C D E F G H J K L MA.TRACK NUMBER display B. PLAY indicator C.TOTAL TIME indicator D.REMaining time indicator E.PLAYING TIME display F.PROGRAM indicatorG.SCAN indicator H.SHUFFLE PLAY indicator J.A « B PLAY indicator K.REPEAT indicator L.REPEAT 1 indicator M.PAUSE indicatorPage Three
