Page 1
Profiler Model 5 Compact Stereo Guitar Amplifier with DSP 2 IMPORTANT SAFETY INSTRUCTIONS - READ, FOLLOW, HEED, AND KEEP ALL INSTRUCTIONS AND WARNINGS.- DO NOT OPERATE NEAR ANY HEAT SOURCE AND DO NOT BLOCK ANY VENTILATION OPENINGS ON THIS APPARATUS. FOR PROPER OPERATION, THIS UNIT REQUIRES 3 (75mm) OF WELL VENTILATED SPACE AROUND HEATSINKS AND OTHER AIR FLOW PROVISIONS IN THE CABINET. - DO NOT USE THIS APPARATUS NEAR SPLASHING, FALLING, SPRAYING, OR STANDING LIQUIDS.- CLEAN ONLY WITH LINT-FREE DAMP CLOTH AND DO NOT USE CLEANING AGENTS.- ONLY CONNECT AC ADAPTER TO A POLARIZED, SAFETY GROUNDED OUTLET WIRED TO CURRENT ELECTRICAL CODES AND COMPATIBLE WITH VOLTAGE, POWER, AND FREQUENCY REQUIREMENTS STATED ON THE APPARATUS. - PROTECT THE POWER CORD FROM DAMAGE DUE TO BEING WALKED ON, PINCHED, OR STRAINED.- UNPLUG THE APPARATUS DURING LIGHTNING STORMS OR WHEN UNUSED FOR LONG PERIODS OF TIME.- ONLY USE ATTACHMENTS, ACCESSORIES, STANDS, OR BRACKETS SPECIFIED BY THE MANUFACTURER FOR SAFE OPERATION AND TO AVOID INJURY. - WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK OR FIRE, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE.- SERVICE MUST BE PERFORMED BY QUALIFIED PERSONNEL.- OUR AMPLIFIERS ARE CAPABLE OF PRODUCING HIGH SOUND PRESSURE LEVELS. CONTINUED EXPOSURE TO HIGH SOUND PRESSURE LEVELS CAN CAUSE PERMANENT HEARING IMPAIRMENT OR LOSS. USER CAUTION IS ADVISED AND EAR PROTECTION IS RECOMMENDED IF UNIT IS OPERATED AT HIGH VOLUME. - WARNING: WHEN USING THE AC ADAPTER, CONNECT TO AN OUTLET WIRED TO CURRENT ELECTRIC CODES HAVING THE LINE SUPPLY VOLTAGE, POWER, AND FREQUENCY IDENTIFIED ON THE AC ADAPTER. THE OUTLET MUST REMAIN ACCESSIBLE TO DISCONNECT THE UNIT IF A FAULT SHOULD ARISE WHILE IN USE. THIS UNIT SHOULD BE UNPLUGGED WHEN NOT IN USE. CAUTIONRISK OF ELECTRIC SHOCK DO NOT OPEN WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN OR MOISTURE. TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER. NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. "IT IS NECESSARY FOR THE USER TO REFER TO THE INSTRUCTION MANUAL" ES NECESARIO QUE EL USUARIO SE REFIERA AL MANUAL DE INSTRUCCIONES. "REFERREZ-VOUS AU MANUAL D'UTILISATION" EXPLANATION OF GRAPHICAL SYMBOLS: EXPLICACION DE SIMBOLOS GRAFICOS: EXPLICATION DES SYMBÔLES GRAPHIQUES: "DANGEROUS VOLTAGE" VOLTAJE PELIGROSO "DANGER HAUTE TENSION"= = PRECAUCIONRIESGO DE CORRIENTAZO NO ABRA PRECAUCION: PARA REDUCIR EL RIESGO DE INCENDIOS O DESCARGAS ELECTRICAS, NO PERMITA QUE ESTE APARATO QUEDE EXPUESTO A LA LLUVIA O LA HUMEDAD. PARA DISMINUOIR EL RIESGO DE CORRIENTAZO. NO ABRA LA CUBIERTA. NO HAY PIEZAS ADENTRO QUE EL USARIO PUEDO REPARAR DEJE TODO MANTENIMIENTO A LOS TECHNICOS CALIFICADOS. ATTENTIONRISQUE D'ELECTROCUTION NE PAS OUVRIR ATTENTION: PROTÉGEZ CET APPAREIL DE LA PLUIE ET DE L'HUMIDITÉ AFIN D'ÉVITER TOUT RISQUE D'INCENDIE OU D'ÉLECTROCUTION. POUR REDUIRE D'ELECTROCUTION NE PAS ENLEVER LE COUVERCLE. AUCUNE PIECE INTERNE N'EST REPRABLE PAR L'UTILISATEUR. POUR TOUTE REPARATION, S'ADRESSER A UN TECHNICIEN QUALIFIE. TABLE OF CONTENTS Introduction .............................................................. 3 Profile. Tracking ......................................................... 4 The. Top.Panel ........................................................... 5 The. Rear. Panel ......................................................... 6 The. DSP. Section ....................................................... 7 Installing. Tracktion .................................................... 9 System. Block.Diagram ............................................ 10 Profiler. Model.5.Technical.Specifications .................. 12 Service. Information ................................................. 12
Page 2
Profiler Model 5 Compact Stereo Guitar Amplifier with DSP Introduction Congratulations! .You. are.now. the.proud. owner. of.the. Crate. Profiler. Model.5.compact. five-watt. stereo. guitar.amplifier. with.advanced. digital.signal.processing. (DSP).and.11.classic. amp.pro - files.. This.portable. amplifier. has.guitar. strap.pegs.on.each. side.for.hands-free. transport,.and. a. battery. compartment. for.operating. when.AC.power. isnt.available. This. rugged. amplifier. combines. outstanding. features.with.serious. clean.and.distorted. sounds.. Digital. Reverb,. Delay,.and.Effects. provide. you.with. a.wide. variety. of.stereo. sounds.. Crates. unique. Profile.Tracking. feature.automatically. stores.your.DSP.settings. for.each. profile. to. memory.. As.you. switch. from.one.profile. to.another,. the.last. DSP. settings. for.the. selected. pro - file. are. instantly. recalled.. A.rear. panel. 1/8".stereo. audio.input.jack.allows. you.to.play. along. with. your. CD.player,. MP3.player,. or.iPod.. There. is.also. a.headphone. output.for.private. listen - ing,. and.a.jack. for.connecting. the.supplied. AC.adapter. whenever. AC.power. is.available. The. Profiler. Model.5.also. includes. a.CD-R. with.Tracktion,. Mackies.powerful. audio.and.MIDI. sequencing. software.for.digital. recording. on.a.PC. or.Mac.. Simply. connect. the.USB. port.on. the. Profiler. Model.5.to. your. computer. and.record. your.music. into.Tracktion. (or.any. other. DAW. software. application). Like. all.Crate. products,. your.Profiler. Model.5.amplifier. is.designed. by.musicians. and.built. using. only.the.best. components.. Extensive.testing.confirms. that.this.amplifier. is.the. absolute. best. it.can. be..In.order. to.get. the.most. out.of.your. new.amplifier,. we.strongly. urge.you.to. read. this.manual. before.you.begin. playing. And. thank you .for. choosing. Crate. Here. are.some. of.the. features. packed.into.your. new.Profiler. Model.5.Stereo. Combo. Amplifier: -. 5.watts. rms.power. output -. 2.x.4". speakers -. 11.digitally. controlled. analog.classic. amp.profiles -. Proprietary. Tone.EQ.control -. Stereo. DSP.Effects. including. Delay,.Modulation. Effects,.and.Reverb. sections -. Audio. Input -. Headphone. Output -. USB. Port -. AC.Adapter. or.battery-powered -. Tracktion. software.application. included 3
