Extracted text from crate kx 50 manual en (Ocr-read)
Page 1
KX-50 Keyboard Amplifier 1: INST. 1 INPUT JACK: Plug any low to line level signal (key- board, synthesizer/sampler, drum machine, tape deck, etc.) here. Use the Mixer Level 1 control (#3) to adjust the signal strength at this input. 2: INST. 2 INPUT JACK: Plug any low to line level signal (key- board, synthesizer/sampler, drum machine, tape deck, etc.) here. Use the Mixer Level 2 control (#4) to adjust the signal strength at this input. 3: MIXER LEVEL 1 CONTROL:Adjust the level of the Instrument 1 signal with this control. Low output instruments may need a setting in the 5-10 range while instruments with hotter outputs may need a setting between 0 and 5. The best setting will cause the peak indi- cator (#5) to flash occasionally while playing. Too low a setting may increase background noise while too high a setting may cause harshness or distortion. 4: MIXER LEVEL 2 CONTROL:Adjust the level of the Instrument 2 signal with this control. Low output instruments may need a setting in the 5-10 range while instruments with hotter outputs may need a setting between 0 and 5. The best setting will cause the peak indi- cator (#5) to flash occasionally while playing. Too low a setting may increase background noise while too high a setting may cause harshness or distortion. 5: PEAK INDICATOR LED:This LED will light when the input lev- els are high enough to cause undesirable clipping and distortion. When levels are too high this LED may stay on continuously. If this happens, reduce the Level controls until the LED flashes occasion- ally at peak signals. 6: LOW CONTROL:Adjust the output level of the low tones with this control. The center position is flat (no boost or cut). Turning the control to the left reduces the output level of the low tones, turning it to the right boosts their level. This control allows a 26dB range of boost or cut at 100Hz. 7: MID CONTROL:Adjust the output level of the midrange tones with this control. The center position is flat (no boost or cut). Turning the control to the left reduces the output level of the midrange tones, turning it to the right boosts their level. This control allows a 24dB range of boost or cut at 700Hz. 8: HIGH CONTROL:Adjust the output level of the high tones with this control. The center position is flat (no boost or cut). Turning the control to the left reduces the output level of the high tones, turning it to the right boosts their level. This control allows a 26dB range of boost or cut at 8kHz.9: REVERB CONTROL:Adjust the amount of reverberation effect with this control. At the extreme left (0) position the signal is dry - no reverb effect is added. As the control is rotated to the right the amount of reverb increases, giving a concert hall fullness to the sound. The reverb control affects both input channels. 10: MASTER VOLUME CONTROL:Use this control to adjust the output level of the amplifier, as well as the signal level at the Line Out and Headphone jacks (#12 and 13). At the extreme left (0) position there will be no output; rotating the control to the right increases the output power. 11: LIMIT:When a power amplifier reaches maximum output levels it may begin to clip its output signal which generates potentially speaker-damaging distortion. The KX-50 has a special APM (Automatic Power Maximizer) limiting circuit which helps minimize this problem by monitoring the power amplifiers output signal, keep- ing it below clipping. This feature insures you that the sound from your amplifier remains clean and pure even at full power. The APM indicator will only light when the amplifier is near clipping: flashing at peak playing levels is acceptable, however if the light remains on constantly, reduce the Master Volume until the light flashes. 12: INSERT/LINE OUT JACK:This jack provides you with an effects loop into the KX-50s power amp. The jack requires a 1/4 stereo phone plug with two shielded cables in a Y type configura- tion. The ring is LINE OUT, the tip is LINE IN and the sleeve is a common ground. This jack can also be used as a line out tap by inserting a 1/4 mono phone plug half way into the jack. This does not interrupt the signal going to the power amp. 13: HEADPHONES JACK:For private practice sessions plug a pair of stereo headphones into this jack. The KX-50s internal speaker is disconnected when the headphone jack is used. 14: ON INDICATOR:This indicator will be lit when the amplifier is on. 15: POWER SWITCH:This switch turns the amplifier on in the right position and off in the left position. 16: POWER CORD:(Rear panel, not shown) This heavy-duty grounded three-wire power cord. is to be plugged into ONLY a safe- ly-wired, grounded 120 volt, 60 cycle AC power outlet. DO NOT attempt to defeat the ground connection on this cord. If your KX-50 was purchased outside of the United States, refer to the rear panel its power requirements and follow the above guidelines.
Page 2
The KX-50 is covered with a durable black Tolex material: wipe it clean with a lint-free cloth. Never spray cleaning agents onto the cabinet. Avoid abrasive cleansers which would damage the finish. El KX-50 esta cubierto con un material durable Tolex: limpielo con una toalla seca. Nunca rocie el gabinete con sustancias limpiadoras. Evite usar materiales abrasivos con los cuales pueda danar el acabado. Le KX-50 est couvert avec «Tolex» un recêtement noir et durable. Essuyez cette matière avec une toile propre et sans charpie. Ne pulvérisez jamais les agents de nettoyage sur l'appareil. Evitez les nettoyeurs abrasifs qui peuvent endommager le «Tolex.» INST. 1INPUTS LEVEL 1 MASTER VOLUME PEAK INST. 2 LEVEL 2 POWER AMP LO MID HI EQ LIMITER LIMIT REVERB LEVEL REVERB INSERT EXT. SPEAKER HEAD PHONES SYSTEM BLOCK DIAGRAM: Crate continually develops new products, as well as improves existing ones. For this reason, the specifications and information in this Crate manual are subject to change without notice. Crate continuamente desarrolla nuevos productos, así como también mejora los existentes. Por esta razón, las especifaciones é información incluidos en este manual están sujetos a cambios sin previo aviso. Crate développe contimuellement des nouvels produits, ainsi d'améliorer ceux qui existe. Pour cette raison les spécifications et les informations dans ce manuel peuvent se changer sans préavis. KX-50 Keyboard Amplifier
