Crate GT 80DSP Owners Manual

Page 1

GT-8ODSP

QuadraDrive'm
Amplifier with

Digital Sound Processing

OWNER'S MANUAL

Page 2

Meet-sons? W

ntl n!

You are now the proud owner of one of the newest and most innovative guitar amplifiers available.
the Crate GT~BODSP OuadraDriva" with Digital Sound Processing. This versatile and compact am-
plifier features four separate. foolswitchable Gain controls. with your choice of Tube or Solid State
preamps for either the Rhythm or the Lead channel. Discrete tones and Master Level controls for each
channel. along with Crate's exclusive Tube Driven Mosfet power amp, add even more flexibility and
control,

The easy to operate Digital Sound Processing section offers you a wide variety of effects, from
some of the finest revert) settings to the truly bizarre. A unique feature of the Digital Sound Processing
is its ability to 'remember' settings for each preamp and channel selection.

Like all Crate products. your GT-BODSP is proudly made in America, using only the best compo-
nents. Extensive testing at the hands (and ears) of skilled technicians and musicians insures you that
this amplifier is the absolute best it can be:

In order to get the most out of your new amplifier, we strongly urge you to go over the information
contained in this manual betore you begin playing,

0
And Wfor choosing
f TAELLOUXDJENLS;
' About the GT-BODSP: 3
The GT-aODSP Front Panel: 4-6
The GT-SODSP Rear Panel: 7
About the Digital Sound Processor:
Using the Mode control: 8
5 Table of Settings: 9
i Technical Description: 10
{ Block Diagrams: 11
E Some Suggested Settings: 12-13
S System Block Diagram: 14
I Technical Specifications: 15
