Page 1
CA15 Acoustic Amplifier IMPORTANT SAFETY INSTRUCTIONS -READ, FOLLOW, HEED, AND KEEP ALL INSTRUCTIONS AND WARNINGS. -DO NOT OPERATE NEAR ANY HEAT SOURCE AND DO NOT BLOCK ANY VENTILATION OPENINGS ON THIS APPARATUS. FOR PROPER OPERATION, THIS UNIT REQUIRES 3 (75mm) OF WELL VENTILATED SPACE AROUND HEATSINKS AND OTHER AIR FLOW PROVISIONS IN THE CABINET. -DO NOT USE THIS APPARATUS NEAR SPLASHING, FALLING, SPRAYING, OR STANDING LIQUIDS. -CLEAN ONLY WITH LINT-FREE DAMP CLOTH AND DO NOT USE CLEANING AGENTS. -ONLY CONNECT POWER CORD TO A POLARIZED, SAFETY GROUNDED OUTLET WIRED TO CURRENT ELECTRICAL CODES AND COMPATIBLE WITH VOLTAGE, POWER, AND FREQUENCY REQUIREMENTS STATED ON THE REAR PANEL OF THE APPARATUS. -PROTECT THE POWER CORD FROM DAMAGE DUE TO BEING WALKED ON, PINCHED, OR STRAINED. -UNPLUG THE APPARATUS DURING LIGHTNING STORMS OR WHEN UNUSED FOR LONG PERIODS OF TIME. -ONLY USE ATTACHMENTS, ACCESSORIES, STANDS, OR BRACKETS SPECIFIED BY THE MANUFACTURER FOR SAFE OPERATION AND TO AVOID INJURY. -WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK OR FIRE, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE. -SERVICE MUST BE PERFORMED BY QUALIFIED PERSONNEL. -OUR AMPLIFIERS ARE CAPABLE OF PRODUCING HIGH SOUND PRESSURE LEVELS. CONTINUED EXPOSURE TO HIGH SOUND PRESSURE LEVELS CAN CAUSE PERMANENT HEARING IMPAIRMENT OR LOSS. USER CAUTION IS ADVISED AND EAR PRO- TECTION IS RECOMMENDED IF UNIT IS OPERATED AT HIGH VOLUME. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN OR MOIS- TURE. TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER. NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. "IT IS NECESSARY FOR THE USER TO REFER TO THE INSTRUCTION MANUAL" ES NECESARIO QUE EL USUARIO SE REFIERA AL MANUAL DE INSTRUCCIONES. "REFERREZ-VOUS AU MANUAL D'UTILISATION" EXPLANATION OF GRAPHICAL SYMBOLS: EXPLICACION DE SIMBOLOS GRAFICOS: EXPLICATION DES SYMBÔLES GRAPHIQUES: "DANGEROUS VOLTAGE" VOLTAJE PELIGROSO "DANGER HAUTE TENSION" == PRECAUCIONRIESGO DE CORRIENTAZO NO ABRA PRECAUCION: PARA REDUCIR EL RIESGO DE INCENDIOS O DESCARGAS ELECTRICAS, NO PERMITA QUE ESTE APARATO QUEDE EXPUESTO A LA LLUVIA O LA HUMEDAD. PARA DISMINUOIR EL RIESGO DE CORRIENTAZO. NO ABRA LA CUBIERTA. NO HAY PIEZAS ADENTRO QUE EL USARIO PUEDO REPARAR DEJE TODO MANTENIMIENTO A LOS TECHNICOS CALIFICADOS. ATTENTIONRISQUE D'ELECTROCUTION NE PAS OUVRIR ATTENTION: PROTÉGEZ CET APPAREIL DE LA PLUIE ET DE L'HUMIDITÉ AFIN D'ÉVITER TOUT RISQUE D'INCENDIE OU D'ÉLECTROCUTION. POUR REDUIRE D'ELECTROCUTION NE PAS ENLEVER LE COUVERCLE. AUCUNE PIECE INTERNE N'EST REPRABLE PAR L'UTILISATEUR. POUR TOUTE REPARATION, S'ADRESSER A UN TECHNICIEN QUALIFIE. Introduction: Congratulations! You are now the proud owner of one of Crates latest contributions to the world of acoustic amplification, the CA15. This compact amplifier delivers over 12 watts of musical power and incorporates two inputs (each with its own gain control), three bands of equalization, and reverb. A pair of RCA- type CD Input jacks allow you to practice with your favorite music. A jack for headphones is provided, along with a jack for connecting the CA15 to an external speaker cabinet. A Crate Custom Design 8woofer delivers smooth clear sound with excellent projection and fidelity. Your CA15 was designed by musicians and built using only the best com- ponents. Extensive testing at the hands (and ears) of skilled technicians and musicians insures you that this amplifier is the absolute best it can be. In order to get the most out of your new amplifier, we strongly urge you to go over the information contained in this manual before you begin playing. And thank you for choosing CRATE.
Page 2
CA15 Acoustic Amplifier The Front Panel: 1,3: Input 1, Input 2.The signal output from your acoustic instrument, tape player, rhythm machine, high-Z microphone or other source may be connected to either or both of these jacks by means of a shielded signal cable. Each of the input jacks is governed by its corresponding gain con- trol (#2 for Input 1, #4 for Input 2). The signals from these two jacks are summed together after their gain stages. 2,4: Gain 1, Gain 2. Use these controls to set the input gain level for the corresponding input jack. These controls set the level of the input signal and serve as the amplifi- er s volume controls. 5: Low.This serves as the bass control for both channels. Adjust this control to get the best sounding bass response for your instrument. Excessive boost of the low control can cause an unnatural howling (acoustic feedback from your instrument) and should be avoided. 6: Mid.This serves as the midrange control for both channels. Adjust this control to get the best projection and midrange tones for your instrument. 7: High.This serves as the treble control for both channels. Adjust this control so your high notes and harmonic overtones are lively but not overpowering. 8: Reverb Level:Use this control to adjust the amount of reverberation added to the signal. In the fully counter clockwise posi- tion, the signal is dry (no reverb added). As you rotate the control clockwise the amount of reverb increases.9: CD Input. Use these jacks to connect the output from a CD player, tape deck, or rhythm machine to the amplifier. The CD Input jacks are post EQ and Gain, so use the level control on the CD player (etc.) to adjust the level of the signal at these jacks. 10: Headphones.Use this jack to connect headphones to the amplfier. The internal speaker is disconnected when this jack is used. 11: External Speaker.Use this jack to connect the amplifier to an external speaker. The internal speaker is disconnected when this jack is used. The impedance of the external speaker must be 4 ohms or greater. Do not attempt to use head- phones in the External Speaker jack! Permanent hearing damage could result. 12: Power Switch. (Rear panel, not shown) Use this switch to apply power to the amplifier: the amp is on when the top of the switch is depressed, off when the bot- tom of the switch is depressed. The switch illuminates when the amp is on. 13: AC Line Cord. (Rear panel, not shown) The grounded power cord should only be plugged into a grounded power outlet that meets all applicable electrical codes and is compatible with the voltage, power, and frequency requirements stated on the rear panel. Do not attempt to defeat the safety ground connection. 1 2 3 6 7 8 9 4 5 10 11
