Classe audio omega monaural owners manual
This is the 12 pages manual for classe audio omega monaural owners manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from classe audio omega monaural owners manual (Ocr-read)
Page 1
LNE A.C. \bNLET OUT\fUTS-+ INPUTS FUSE \bR \bN OUT L\bNE BALANCED D\bSCONNECT A.C. L\bNE \SBEFORE W\bTH SAME TY\fE AND RA\ST\bNG ONLY O\fEN\bNG UN\bT RE\fLACE \SFUSE WARN\bNG ALWAYS TURN OFF UN\bT \SBEFORE BEFORE CONNECT\bNG TO \SA.C. L\bNE CHECK O\fERAT\bNG VOLTA\SGE AND CONNECT\bONS ACT\bVAT\bNG ALL SW\bTCHE\SS Figure 1 – Omega monaural amplifier – rear view Figure 2 – Omega monaural amplifier – wall plug Analog Inputs Speaker Outputs IR Input and Output AC Power Input Earth pin Live pin Neutral pin Live pin Neutral pin Earth Earth pin Live pin Neutral pin
Page 2
SAFETY PRECAUTIONS Warning:failure to comply with these safety instructions can cause serious injury or death, or cause your Classé Omega Monaural Power Amplifier to be severely damaged or destroyed. Do not operate the Classé Omega Monaural Power Amplifier with any portion of the chassis removed or open. Dangerous voltages may be encountered. Connecting this unit to AC voltages other than that specified on the rear of the unit may cause extensive damage and increase risk of shock. Check to make sure your local AC voltage matches the voltage specified on the rear of your Classé Omega Monaural Power Amplifier. Do not operate this product near sources of heat such as radiators, fireplaces, or heat registers. Extreme heat may damage this unit. To reduce the risk of electric shock or fire do not expose this unit to water or moisture. Use only the correct size fuse: - 100-110 Volts 15 Amp, 3AG Slo-Blo - 220-240 Volts 12 Amp, 3AG Slo-Blo Do not open this unit. There are no user serviceable parts inside. Please refer service to an authorised service technician. Unplug this unit when unused for long periods or during lightning storms. INTRODUCTION Congratulations Congratulations on your new purchase. From all of us at Classé, we hope you enjoy many years of musical satisfaction from your new Classé Omega Monaural Power Amplifier. How to use this manual The symbol at left indicates a section of the manual that is of particular importance for safety or to prevent damage to your Omega Monaural Power Amplifier. Please make note of all safety precautions described in the previous section of this manual. It is highly recommended that you familiarize yourself with all aspects of the operation of your Omega Monaural Power Amplifier. However, if you want to begin listening to your Omega Monaural Power Amplifier immediately, skip to the section titled Connections. Classé Omega Monaural Power Amplifier: Design Overview The Classé Omega Monaural Power Amplifier is the result of repeated listening design sessions. The sound is fine tuned by the exchanging and mixing of parts and the adjusting of many specific operating voltages. The result of these sessions is a sonic recipe that yields a natural harmonic realism typical of instruments in a live performance. Unique Circuit Design The Classé Omega Monaural Power Amplifier circuitry design is a completely new design by Classé Audio. This unique design utilizes 64 output devices in a special arrangement designed to maintain internal rail voltage under the most adverse conditions. The 64 output devices are divided evenly, 32 being utilized to maintain rail voltage, and the other 32 utilized as output power devices. The result of this unique design is an amplifier which offers uncompromised performance even under the most adverse conditions. 1 !
