Classe audio cp 65 owners manual
This is the 47 pages manual for classe audio cp 65 owners manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Page: 1 / 47
Extracted text from classe audio cp 65 owners manual (Ocr-read)
Page 1
Figure 1 – CP-65 Rear panel – Main Unit and External Power Supply Figure 2 – Balanced input and output sockets Main Unit External Power Supply DC Output to Main unit INPUT (Female): PIN 1: Ground PIN 2: Positive signal PIN 3: Negative signal OUTPUT (Male): PIN 1: Ground PIN 2: Positive signal PIN 3: Negative signal AC Line In Power Switch
Page 2
Figure 3. CP-65 – Front panel Figure 4. Remote Control handset STANDBY INPUT Selector MUTE VOLUME TAPE MONITOR
