Classe audio cddvd 1 owners manual
This is the 15 pages manual for classe audio cddvd 1 owners manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from classe audio cddvd 1 owners manual (Ocr-read)
Page 1
SAFETY INFORMATION CAUTION:Please read and observe all warnings and instructions in this owners manual and all those marked on the unit. Retain this owners manual for future reference. 1.Do Not Open the CD/DVD-1 for any reason, as there are no user serviceable parts inside. An open unit, particularly if it is still connected to an AC source, presents a potentially lethal shock hazard. Refer all questions to authorized service personnel only. Do not attempt to service this product yourself. 2.Do Not Defeat AC ground. Do not remove any of the connectors on the AC plug. Do not attempt to defeat the ground connection with a cheater plug or a 3-wire to 2-wire plug. If you attempt to defeat the ground connection you may cause a lethal injury to yourself or others. 3.To prevent fire or shock hazard, do not expose the CD/DVD-1 to water or moisture. 4.Do not place the CD/DVD-1 close to any heat- producing device such as your audio amplifier(s), and also keep it away from direct sunlight, a radiator, stove, etc. 5.Connect the CD/DVD-1 only to an AC source of the proper voltage. The shipping container and the rear panel serial number tag will stipulate the proper voltage. Use of any other voltage will almost certainly damage the unit and will void the warranty. 6.If the CD/DVD-1 will be out of use for an extended period of time (vacation, etc.), you may wish to unplug the power cord from the AC source to prevent any chance of problems from a voltage surge or lightning strike. (See section 1.4). 7.Keep your fingers well clear of the disc tray as it is closing. It may cause serious personal injury. Do not place anything other than a CD or DVD in the disc tray, as any other object may permanently damage the mechanism. 8.This player contains a Laser: Do not look into the opening of the disc tray or ventilation opening of the product to see the source of the laser beam, because the laser beam may cause permanent damage to your eyes. 9.Do not place a heavy object on or step on the player. 10.Do not use a cracked, deformed, or repaired disc. CD and DVD discs are easily broken and may cause serious personal injury and product malfunction. CE NOTICE All of us at Classé take extreme care to insure that your purchase will remain a prized investment. We are proud to inform you all Classé Audio components have been officially approved for the European Community (CE) mark under CE Certificate Number C401CLA1.MGS granted on 18 July, 1996. This means that your Classé product was subjected to the most rigorous manufacturing and safety tests in the world. The CE mark certifies that your purchase meets or exceeds all European Community requirements for unit-to-unit consistency and consumer safety. The CD/DVD-1 is manufactured under license from Dolby Laboratories Licensing Corporation. It is additionally licensed under one or more of the following patents: U.S. number 3,959,950, Canadian numbers 1,004,603 and 1,037,877. Manufactured under license from Lucasfilm Ltd. U.S. patent numbers 5,043,970; 5,189,703; and 5,222,059. European patent 0 323 830. Other patents pending. Additionally, the CD/DVD-1 is manufactured under license from Digital Theater Systems, Inc. Dolby® Pro Logic®, and Dolby Digital® are registered trademarks of Dolby Laboratories Licensing Corporation. DTS® is a registered trademark of Digital Theater Systems, Inc. THANK YOU FROM EVERYONE AT CLASSÉ Thank you for purchasing the Classé Audio CD/DVD-1 CD/DVD player. We take great pride in offering components that combine exceptional sonic performance and long- term reliability. To do that, we have invested in extraordinary design and manufacturing facilities. We trust that you will enjoy your purchase for many years to come. CLASSÉ DESIGN PHILOSOPHY All of our components benefit from the same rigorous design goal: All Classé products must reproduce music with the harmonic and spatial integrity typical of fine instruments heard in a live, unamplified performance. SINGLE CIRCUIT DESIGN To this end, we make extensive use of carefully optimized versions of the same basic circuit precisely matched to specific power requirements. This means that all Classé line level components and power amplifiers benefit from years of refinement. However, our efforts do not stop here.LISTENING: THE CRITICAL DESIGN ELEMENT Once we determine general circuit values for a particular application, we listen carefully while exchanging and mixing different parts (transistors, capacitors, wiring, PC boards, etc). and adjusting specific operating voltages within proper engineering ranges. EXTENDED REAL-WORLD LIFESPAN Every Classé component, even the most affordable, benefits from our painstaking approach to design parameters. The result is an optimum balance between the often-conflicting demands of exceptional performance and long-term reliability. Our most expensive components gain from even tighter tolerance parts and highly segmented and exceptionally robust power supplies with large reserve-current capabilities. OUR PRIDE IN MANUFACTURING, YOUR PRIDE IN OWNERSHIP. We build all of our components to the highest possible standards. From multi-layer glass-epoxy circuit boards, the full sized power-supplies, and the massive faceplates, every Classé product is a tribute to both the science and art of sound reproduction. We hope that you derive as much pleasure and satisfaction in using your Classé as we did in producing it. The Classé CD/DVD-1 Compact Disc and Digital Video (or Versatile) Disc Player and Transport is a simple and intuitive piece which simultaneously delivers analog and digital audio output, along with Component Video, S-Video and Composite Video output. It makes Music out of data. It makes Movies out of data. The CD/DVD-1 is the high quality Digital beginning of any audio and home theater installation. It will sound and work best in your system when used with other high end products, such as those from Classé. Classé has a powerful selection of Surround Sound Processors, single, dual and multi channel Power Amplifiers, and an equally strong selection of Tuners, CD players, and SACD players (2001 release). This owners manual will make it possible for you to set up the CD/DVD-1 and begin using it only a very few minutes after you take it out of the box. The first section sets out the precautions which should be taken when first setting it up, and the second section details how to plug in the Digital, Analog Audio and Video cables into your Surround Processor and/or TV (Projector). The most difficult part of the set-up will be attaching all the wires. Classé recommends labeling each and every input or output wire in your entire Music/Theater system, including even the AC cables. When youve done this you will know what equipment is connected at each end. Labeling is a simple task which takes a little extra time, but it can save hours of effort if you ever want to change anything, even a single piece of wire. We feel it is a good idea to make a chart of all the associated equipment and how you want to attach everything together. Even a simple penciled flow chart will make your task go faster with fewer hook up errors. You can keep the chart for later reference when you want to add or subtract equipment to the system. 2
Page 2
3 CONTENTSIntroduction Safety Information 2 CE Notice 2 Thank You 2 Classé Design Philosophy 2 About This Manual 2 SECTION 1.0 Getting Started, taking Precautions 4 1.1 Unpacking the CD/DVD-1 4 1.2 Optimal Placement 4 1.3 Ventilation and Proper Placement 4 1.4 Moisture Condensation 4 1.5 Placement Behind Cabinet Doors 4 1.6 Shipping or Moving 4 SECTION 2.0 Installation Overview 5 2.1 Video outputs 5 2.1.1 Component Video 5 2.1.2 S-Video 5 2.1.3 CVBS or Composite Video 5 2.2 Digital Audio Outputs 5 2.2.1 TOSlink 5 2.2.2 AES/EBU 5 2.2.3 Coaxial 5 2.3 Analog Audio Outputs 5 2.3.1 Balanced Connections 5 2.3.2 Coaxial Connections 5 2.4 A.C. Connections 5 2.4.1 AC Cable 5 SECTION 3.0 CD/DVD-1 Front Panel Controls and Display 6 3.1 Front Panel Buttons 6 3.1.1 Load Button 6 3.1.2 Standby Light 6 3.1.3 Display 6 3.1.4 Power Button 6 3.1.5 Jump Buttons 6 3.1.6 HDCD light 6 3.1.7 Stop Button 6 3.1.8 Play Button 6 3.1.9 Pause Button 6 3.1.10 Fast Forward and Reverse 6 3.1.11 Waiting for Input 6 SECTION 4.0 CD/DVD-1 Panel Display Information 7 4.1 Display 7 4.1.1 Blinking Symbol 7 4.1.2 Shuffle 7 4.1.3 Pause 70 4.1.4 A-B 7 4.1.5 Repeat 7 4.1.6 Chapter 7 4.1.6a Title 7 4.1.6b Track 7 4.1.7 Title 7 4.1.8 Chapter 7 4.1.9 Track 7 4.1.10 Time 7 4.1.11 Track 7 4.1.12 Total 7 4.1.13 Close 7 4.1.14 Read 7 4.1.15 Open 7 4.1.16 Title number 7 4.1.17 Chapter Number 7 4.1.18 Track Number 7 4.1.19 DVD Symbol 7 4.1.20 CD Symbol 7 4.1.21 Track/Chapter Numbers 8 4.1.22 Info 8 4.1.23 Total Time 8 4.1.24 DVD Played Time 8 4.1.25 DVD Total Time 8 SECTION 5.0 CD/DVD-1 Remote Control Wand 8 SECTION 6.0 Setting Up the CD/DVD-1 10 6.1 Setting up the CD/DVD-1 Is easy 10 6.1.1 Powering up for first time 10 6.1.2 Setup Key 10 6.1.3 Choose Language 10 6.1.3.1 Spoken language Advisors 10 6.1.4 Subtitle 10 6.1.4.1 Subtitle Advisory 10 6.1.5 Parental Control 10 6.1.5.1 Authorization of Discs 10 6.1.5.2 Deactivate Parental Control 10 6.1.5.3 Forgotten PIN 10 6.1.6 TV Shape 10 6.1.7 Auto-play 10 6.1.8 Auto FTS 10 6.1.8.1 OSD and FTS 10 6.1.8.2 Start of FTS 10 6.1.8.3 Include Tracks on FTS 11 6.1.8.4 Exclude Tracks on FTS 11 6.1.8.5 Too many discs and FTS 11 6.1.9 Digital Output 11 6.1.10 Sound 11 6.1.11 Video Shift 11 6.1.12 PBC 11 6.1.13 OSD Language 11 6.1.14 Exit setup 11 SECTION 7.0 Using the CD/DVD-1 11 7.1 Playing a DVD Video Disc 11 7.1.1 Play a Title 11 7.1.1.1 Title Menu Advisory 11 7.1.2 Stop Play 11 7.1.2.1 Resume 12 7.1.3 Skip Chapter 12 7.1.4 Skip Title 12 7.1.5 Parental Control 12 7.1.6 Still Picture and Pause 12 7.1.7 Search 12 7.1.8 Slow Motion 12 7.1.9 Shuffle 12 7.1.10 Repeat a Portion 12 7.1.10.1 Repeat Methods 12 7.1.10.2 Chapter Repeat 12 7.1.10.3 Title Repeat 12 7.1.10.4 Repeat A-B 12 7.1.10.5 Turn off Repeat 12 7.1.11 Camera Angle 12 7.1.11.1 Camera Angle Icon 12 7.1.11.2 Camera Angle and OSD 12 7.1.12 DVD Menu of Titles 12 7.2 Playing a Video CD 12 7.2.1 Playing a Disc 12 7.2.2 Stop Playing Disc 12 7.2.2.1 Resume Playing a Video CD 12 7.2.3 Skip a Track 12 7.2.4 Skip to another index 13 7.2.5 Playback Control 13 7.2.6 Parental Control 13 7.2.7 Search 13 7.2.8 Slow Motion 13 7.2.9 Shuffle 13 7.2.10 Repeat 13 7.2.10.1 Repeat A-B 13 7.2.10.2 Repeat Track 13 7.2.10.3 Repeat Disc 13 7.2.10.4 Turn off Repeat 13 7.3 Playing an Audio CD 13 7.3.1 Insert and Play 13 7.3.2 Stop Playing CD 13 7.3.3 Pause CD 13 7.3.4 Search CD 13 7.3.5 Skip to another Track on CD 13 7.3.6 Shuffle 13 7.3.7 Repeat 13 7.3.7.1 Repeat A-B 13 7.3.7.2 Repeat Track 13 7.3.7.3 Repeat Disc 13 7.3.7.4 Stop Repeat 13 APPENDIX A RC5 Codes for CD/DVD-1 and Processors 14-15
