Classe audio cav 180 owners manual

This is the 24 pages manual for classe audio cav 180 owners manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.

Page: 1 / 24
classe audio cav 180 owners manual

Extracted text from classe audio cav 180 owners manual (Ocr-read)


Page 1

PUSH 3 12NC3FAH2 PUSH 3 12NC3FAH2 PUSH 3 12NC3FAH2 PUSH 3 12NC3FAH2 PUSH 3 12NC3FAH2 + - OUTPUT CH. 1 + + - - + + - - CH. 4 CH. 3 CH. 2 CH. 5 CH. 1 INPUT FUSE CH. 2 CH. 4 CH. 3 IR L N A.C. INLETIN CH. 5 OUT E Figure 1– Rear panel Figure 2– Wall plug Neutral pin Live pin Analog Inputs Speaker Outputs IR Input and Output AC Power Input

Page 2

1 SAFETY PRECAUTIONS WARNING: failure to comply with these safety instructions can cause serious injury or death, or cause your Classé CAV-180 Multichannel Power Amplifier to be severely damaged or destroyed. Do not operate the Classé CAV-180 Multichannel Power Amplifier with any portion of the chassis removed or open. Dangerous voltages may be encountered. Connecting this unit to AC voltages other than that specified on the rear of the unit may cause extensive damage and increase risk of shock. Check to make sure your local AC voltage matches the voltage specified on the rear of your Classé CAV-180 Multichannel Power Amplifier. Do not operate this product near sources of heat such as radiators, fireplaces, or heat registers. Extreme heat may damage this unit. To reduce the risk of electric shock or fire do not expose this unit to water or moisture. Use only the correct size fuse: - 100-110 Volts 10 Amp, 3AG Slo-Blo - 220-240 Volts 8 Amp, 3AG Slo-Blo Do not open this unit. There are no user-serviceable parts inside. Please refer service to an authorised service technician. Unplug this unit when unused for long periods or during lightning storms. INTRODUCTION Congratulations Congratulations on your new purchase. From all of us at Classé, we hope you enjoy many years of musical satisfaction from your new Classé CAV-180 Multichannel Power Amplifier. How to use this manual The symbol at left indicates a section of the manual that is of particular importance for safety or to prevent damage to your CAV-180 Multichannel Power Amplifier. Please make note of all safety precautions described in the previous section of this manual. It is highly recommended that you familiarize yourself with all aspects of the operation of your CAV-180 Multichannel Power Amplifier. However, if you want to begin listening to your CAV-180 Multichannel Power Amplifier immediately, skip to the section titled Connections. Classé CAV-180 Multichannel Power Amplifier: Design Overview The Classé CAV-180 Multichannel Power Amplifier is the result of repeated listening design sessions. The sound is fine tuned by the exchanging and mixing of parts and the adjusting of many specific operating voltages. The result of these sessions is a sonic recipe that yields a natural harmonic realism typical of instruments in a live performance. Single Circuit Design All Classé Power Amplifiers and Preamplifiers including the CAV-180 Multichannel Power Amplifier share exactly the same circuit design. This means all amplifers and all high level circuits of our preamplifers are the same. The circuit is tailored for different power levels and applications. The differences are found in the complement and the quality of parts, and the power supply sophistication. The result of years of fine tuning is a very high level of understanding and achievement in circuit design that benefits all Classé products. !
