Classe audio 4 brochure

Page 2

6%» Co is © Classé Four FEATURES AND SPECIFICATIONS:

° ° ° ° ° 3 Frequency Response: 20Hz-20Khz +/-0.1 dB
Sensitivity: Line: 120Mv
MM Phono: Phono Models 3Mv
MC Phono: Phono Models 03Mv
Input Impedance: Line: 50 Kohms
MC & MM Phono: Phono Models 47 Kohms
Output Impedance: 1 Ohm
S/N Ratio: Line: 95 dB
MC & MM Phono: Phono Models 85 dB
Gain: Line: 18 dB
MM Phone: Phone Models 35 dB
MC Phono: Phono Models 20-40 dB (adjustable)
Maximum Output: 20 Volts
T.H.D. & I.M. Distortion: 01%
Power Consumption: 50 Watts
Dimensions: [9"x [2 3/8 x 3 5/8
Shipping Weight: [8 lbs.

Standard Finishes: Satin Black, and Soft Shadow Silver.

Inputs: Balanced, MC/MM (Phono Model), Tuner, Tape, CD, AUX, AUXZ (Line Model)
Outputs: Balanced Main Out, Single Ended Main Out, Buflered Tape Out.

Front Panel Functions: Input Selector, Tape Monitor, Balance, Volume, Mute,

The Classé Four brings together world leading levels of engineering, highest quality parts and materials, and a never ending love
formusic, providing an unsurpassed blend of technology, musical petformance and value, while retaining the classic Classe look, feel,
and individuality.

The Four employs sophisticated circuitry using reference quality parts including one percent custom metal-film resistors,
polystyrene and polypropylene capacitors, leading-edge printed circuit boards incorporating specially designed Classé UH C transfer
characteristics, and top quality custom controls and switches, with silver and gold contacts providing quiet trouble free operation.

The F our powersupply uses a high current toroidal transformer capable of several times the required power, 4 stages of regulation,
56,400 UF of filter capacitance, and features proprietary Classé ultrasonic filtering of both the ultra-high beta (current gain) main
output stage, as well as the local supply to the input difierential amplifier.

Balanced input circuitry, and the truly balanced high level section featuring completely discrete individual circuitry for both
positive and inverted, and left and right channels, can be operated simultaneously with the single ended main outputs, or seperately.

0n phono models, all gain stages and equalization feature zero feedback and a passive RIAA network. A precision resistor kit
included provides eleven difierent possible gain settings to accommodate various moving coil cartridges.

Extensive research into mechanical isolation of sensitive signal path circuitry, as well as controlled impedances and voltages,
dramatically reduced vibrations causing microphonics, resulting in previously unattainable levels of transparency, resolution of
detail, soundstage focus, and a clean natural timbre and harmonics.

Unprecedented state of the art music reproduction, and levels of natural musical excitement of the Classé Four have created an
immediate stir, from stereo publications and showrooms worldwide, to the most demanding audio critics and devoted music lovers
alike, thus reinforcing Classes philosophy of repeated listening design sessions, and years of musical fine tuning necessary to
approach the harmonics of music, typically achieved with only the finest quality musical instruments.

Whether judged by its sonic merit or its handcrafted quality, the Classe Four is clearly a reference quality product capable of
complimenting the finest audio system.

Classé Audio Inc., 9414 Cote de Liesse Road, Montreal, Quebec, Canada H8T 1A1 Tel. .- (514 ) 636-6384 Fax: (514 ) 636-1428
