LK-125
-“ 1 -“
SPECIFICATIONS
Keyboard 61 standard-size keys; 5 octaves
Key Light System Can be turned on and off (up to 4 keys can be lit at the same time)
Tones
100 presets
Polyphony
12 notes maximum
3-Step Lesson System
Number of simultaneously lit keys; 4
3-Steps
Playback
1 tune repeat playback
Voice Fingering Guide
On/Off
Auto-accompaniment Rhythm Patterns
50 presets
Tempo
Adjustable, (216 steps,
= 40 to 255), initial value; 120
Chords
Two systems; CASIO CHORD, FINGERED
Other
Fill-in pattern, Synchro start
Song Bank Tunes
100 tunes
Musical Information Function
Tone, Auto Accompaniment, Song Bank numbers and names; tempo,
3 step lesson display, chord name, fingering, timing indicator, key lighting,
voice fingering
Other Functions Transpose
F# to C to F: half-note
Tuning
Adjustable A4 = Approx. 440 Hz ± 50 cents,
Initial value: A4 = Approx. 440 Hz
Speakers
10 cm diameter × 2 (Output: 2 W + 2 W)
I/O Terminals Power Supply
DC 9.5 V jack
Headphones/Output
Stereo standard jack (Output is monaural.)
Output impedance 78 -„¦, output voltage: 4 V (RMS) MAX
Power Supply
2-way
Batteries
6 AA-size zinc-carbon batteries or alkaline batteries
Battery Life:
Approximately 4 hours continuous operation on alkaline batteries
Approximately 1 hour continuous operation on zinc-carbon batteries
AC Adaptor
AD-E95100L
Auto Power Off
Approximately 6 minutes after the last operation
Power Consumption
9.5 V
7.7 W
Dimensions
94.9 × 30.4 × 9.3 cm (37
3/8 × 11 15/16 × 3 11/16 inch)
Weight
Approximately 3.4 kg (7.5 lbs) (without batteries)
