Casio ctk 650 service manual
This is the 22 pages manual for casio ctk 650 service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from casio ctk 650 service manual (Ocr-read)
Page 1
CONTENTS SPECIFICATIONS ....................................................................................................1 BLOCK DIAGRAM ...................................................................................................2 CIRCUIT DESCRIPTION CPU (HD6433298A16P : H8/329) .....................................................................3 DIGITAL SIGNAL PROCESSOR, LSI-S (HG51A115A01FD) ..........................4 KEY TOUCH LSI (HG52E35P) ..........................................................................5 POWER AMPLIFIER (LA4598) .........................................................................6 BUTTON MATRIX ............................................................................................. KEY MATRIX .....................................................................................................8 WIRING DIAGRAM ................................................................................................... IC LEAD IDENTIFICATION AND INTERNAL CIRCUIT ..........................................10 PCB VIEW AND MAJOR WAVEFORMS ................................................................. SCHEMATIC DIAGRAM ........................................................................................... PARTS LIST .............................................................................................................15 EXPLODED VIEW ....................................................................................................197 9 12 13
Page 2
Ñ 1 Ñ Number of keys: 61 Polyphony: 32-note(max.) Preset tones: 128 Magical preset: BREAK BEAT 16 MELODYCOMP 8 SHADOW DRUM 4 FREE SESSION 32 TONE STACK 40 KEY SPLIT 12 HYPERACTIVE 16 Auto-accompaniment: Rhythm patterns 128 Tempo Adjustable(40 - 255) Chords Three system: CASIO CHORD, FINGERD, FULL-RANGE CHORD Other Variation pattern, fill-in pattern, intro/ending pattern for each rhythm. Song memory: song:one System:Real-time recording Memory capacity:Up to 1,300 notes Registration memory: 4 setups Sound control pads: Phrases 10 Drums 10 SE/Percussion 10 Controller 2 Digital effects: REVERB 1, REVERB 2, REVERB 3, CHORUS, TREMOLO, PHASE SHIFTER, ORGAN SP, ENHANCER, FLANGER, EQLOUNDNESS DEMO tunes: 3 tunes Other functions: Transpose (F# ~ C ~ F : half-note) Tuning adjustable A4 = 440KHz 50 cents increments Volume control (Main /Accompaniment) Speakers: 12cm diameter X 2 (Output:2W+2W) I/O terminals: Power supply 9V DC jack Headphones Stereo mini jack Output impedance:100 ohm Output voltage:4.5V(RMS. max) Assignable jack Standard jack MIDI IN, OUT Power supply: 3-way AC/DC power sources; Batteries Six D-size Battry life Approximately 5 hours on R20P(SUM-1) AC Required optional AD-5 AC adaptor Car battery Required optional CA-5 car adaptor Auto power off: Approximately 6 minutes after the last operation Power consumption: 7.7W Dimensions: 942 X 367 X 135 mm(HWD) 31 7/16" X 14 1/2" X 4 3/8" inches(HWD) Weight: 5.2kg(11.7lbs) excluding batteries Accessory: Score stand SPECIFICATION
