BRX18BRX12 BRX18BRX10 TYPICAL SETUP BRX enclosures feature four input/output jacks (two 1/4" and two Speakon) wired in parallel. Connect the BRX INPUT to any audio amplifier capable of 8 ohm operation. Connect additional BRX enclosures from the EXT.SYSTEM jack to the INPUT of the additional enclosure (be sure the amplifier is capable of 4 ohm operation). The BRX10 and the BRX12 feature a HIGH FREQUENCY ATTENUATION (dB) switch for accurately adjusting the high frequency level. This is a positive lock switch preset at six levels of attenuation. A good starting point for this switch would be in the -6dB position, or straight up 12 o'clock. As you turn the switch CCW the attenuation doubles to -12dB, then to -24dB, and finally OFF turns the high frequency driver off. Switching CW the attenuation halves to -3dB and then 0dB which turns the high frequency driver full on. Carvin suggests the B-series and R-series bass heads to power the BRX cabinents. BRX SYSTEMS BRX10 BRX12 BRX510 BRX512 BRX1018BRX1218 B500500w mono block bass Head B15001900w mono block bass Head R1000 bass Head R600 bass Head
