POWER Power Amplifier PowerAmplifier 500 Designed and Engineered in London, England INPUT / OUTPUT 12 21 INPUT / OUTPUTLEFT RIGHT POWER AC FOR NORMAL OPERATION USE THESE TERMINALS ONLY FOR BI-WIRE OPERATION USE BOTH SETS OF TERMINALS LEFT +- - RIGHT+ IMPEDANCE 6-8 - LEFT+ +RIGHT LOUDSPEAKER TERMINALS - IMPEDANCE 6-8W CAUTION: SERIAL NUMBER REMOVED Serial No: Model: P500 Power Amplifier Power Rating: Max Power Consumption: 40W 500 Series CAUTION: AVIS: ACHTUNG:RISK OF ELECTRIC SHOCK. DO NOT OPEN. RISQUE DE CHOC ELECTRIQUE. NE PAS OUVRIR. VORM ÖFFNEN DES GERÄTES. NETZSTECKER ZIEHEN. REAR PANEL CONNECTIONS Please refer to page 5 of your owners manual SPECIFICATIONS Input Sensitivity:650mV Input Impedance:47kW Speaker Impedance:6W - 16W Power Output:55 watts rms (6W) Frequency Response: <10Hz to 70kHz (-3dB points) Channel Separation: At 1kHz better than 72dB Distortion: Less than 0.02% @ 1 Watt Signal Noise Ratio (A weighted): 92dB @ full output power Dimensions(mm): 90(h)x430(w)x300(d) Voltage AC: As specified on rear panel Power Consumption: As specified on rear panel Cambridge Audios policy is one of continuous improvement. It is possible therefore, that specifications and designs may change without prior notice. FRONT PANEL CONTROLS Please refer to page 6 of your owner s manual AC Power Socket Loudspeaker Terminals Input / Output Connections Power Switch
