P.50 SERVICE MANUAL

AMENDMENT SHEET |

Fans List

R45 should read 8K2 not 3K9 /

R46 " " 22K " 68K:
R68 " " 120K " 150K

R74 " " 68K " 470K/
R76 " " 8K2 " 6K8 ~
R93 " " 5K6 " 8K2 /
R95 " " 4K7 " 2K7 /
R96 " " 27K " 470R j.
R100 " " 150K " 68K

R86, 98 and 99 not used. 1/
Part numbers are being revised and shouid not be quoted until
a revised list is issued.

Circuit Diagram (Master)
7
L
R86, R98 & 99, 016 a 17 all replaced by link is/ci. / 2- gb r 7

R92 should be R96. \/

R82 adjacent 027 should be R92; i/
