Page 2
640C V2 SERVICE MANUAL - Revision 2
TABLE OF CONTENTS
Safety Precautions & Important Notes
Laser Safety Precautions
Exploded Diagram
Front Panel PCB Schematic (Issue 3)
Front Panel PCB Layout (Top Side)
Front Panel PCB Layout (Bottom Side)
Front Panel PCB Assembly BOM (Issue 2)
Front Panel PCB Assemny BOM (Issue 3)
Servo PCB Schematic
Servo PCB Layout (Top Side)
Servo PCB Layout (Bottom Side)
Servo PCB Assembly BOM
DAC Board PCB Schematic (Issue 6)
DAC Board PCB Schematic (Issue 7)
DAC Board (Supply) PCB Schematic (Issue 6)
DAC Board (Supply) PCB Schematic (Issue 7)
DAC Board PCB Layout (Top Side) (Issue 6)
DAC Board PCB Layout (Top Side) (Issue 7)
DAC Board PCB Layout (Bottom Side) (Issue 6)
DAC Board PCB Layout (Bottom Side) (Issue 7)
DAC PCB Assembly BOM (Issue 3)
DAC PCB Assembly BOM (Issue 6)
Mains PCB Schematic
2|
22
23
2425
26-27
28
Mains PCB Layout (Top Side)
29
Mains PCB Layout (Bottom Side)
Mains PCB Assembly BOM
30
3|
Voltage Select Switch PCB Schematic
Voltage Select Switch PCB Layout (Top Side)
Voltage Select Switch PCB Layout (Bottom Side)
Voltage Selector PCB Assembly BOM
lC Pin Layout Details
32
33
34
35
36-44
