340TFM / AM tuner Azur FM/AM tuner 3 Thank you for purchasing this Cambridge Audio Azur 340T, a newly developed FM/AM tuner to compliment the Cambridge Audio Azur range. About this unit The 340T incorporates sophisticated Alarm and Sleep timer functions that can turn on and off connected Cambridge Audio amplifiers fitted with Control Bus inputs/outputs. A specific version of the azur remote is provided, giving full remote control of the tuner functions in an attractive and easy to use handset. The 340T can only be as good as the system it is connected to. Please do not compromise on your amplifier, speakers or cabling. Naturally we recommend amplification and cabling from the Cambridge Audio range, connected to suitably revealing loudspeakers. The use of an external FM/AM aerial is strongly recommended to get the best from your 340T. Now we invite you to sit back, relax and enjoy ! Matthew Bramble Technical Director INTRODUCTION Limited warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Safety precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Important safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Rear panel connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Front panel controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Operating instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Using the remote handset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 CONTENTS
Page 2
4 Azur FM/AM tuner Checking the Power Supply Rating For your own safety please read the following instructions carefully before attempting to connect this unit to the mains. Check that the rear of your unit indicates the correct supply voltage. If your mains supply voltage is different, consult your dealer. This unit is designed to operate only on the supply voltage and type that is indicated on the rear panel of the unit. Connecting to other power sources may damage the unit. This equipment must be switched off when not in use and must not be used unless correctly earthed. To reduce the risk of electric shock, do not remove the unit's cover (or back). There are no user serviceable parts inside. Refer servicing to qualified service personnel. If the power cord is fitted with a moulded mains plug the unit must not be used if the plastic fuse carrier is not in place. Should you lose the fuse carrier the correct part must be reordered from your Cambridge Audio dealer. The lightning flash with the arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the products enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance instructions in the service literature relevant to this appliance. This product complies with European Low Voltage (73 / 23 / EEC) and Electromagnetic Compatibility (89 / 336 / EEC) Directives when used and installed according to this instruction manual. For continued compliance only Cambridge Audio accessories should be used with this product and servicing must be referred to qualified service personnel.The crossed-out wheeled bin is the European Union symbol for indicating separate collection for electrical and electronic equipment. This product contains electrical and electronic equipment which should be reused, recycled or recovered and should not be disposed of with unsorted regular waste. Please return the unit or contact the authorised dealer from whom you purchased this product for more information. Plug Fitting Instructions (UK Only) The cord supplied with this appliance is factory fitted with a 13 amp mains plug fitted with a 3 amp fuse inside. If it is necessary to change the fuse, it is important that a 3 amp one is used. If the plug needs to be changed because it is not suitable for your socket, or becomes damaged, it should be cut off and an appropriate plug fitted following the wiring instructions below. The plug must then be disposed of safely, as insertion into a 13 amp socket is likely to cause an electrical hazard. Should it be necessary to fit a 3-pin BS mains plug to the power cord the wires should be fitted as shown in this diagram. The colours of the wires in the mains lead of this appliance may not correspond with the coloured markings identifying the terminals in your plug. Connect them as follows: The wire which is coloured BLUE must be connected to the terminal which is marked with the letter N or coloured BLACK. The wire which is coloured BROWN must be connected to the terminal which is marked with the letter L or coloured RED. The wire which is coloured GREEN/YELLOW must be connected to the terminal which is marked with the letter E or coloured GREEN. If your model does not have an earth wire, then disregard this instruction. If a 13 amp (BS 1363) plug is used, a 3 amp fuse must be fitted, or if any other type of plug is used a 3 amp or 5 amp fuse must be fitted, either in the plug or adaptor, or on the distribution board. SAFETY PRECAUTIONS
