Cambridgeaudio 540A V2 int sm
This is the 42 pages manual for cambridgeaudio 540A V2 int sm.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from cambridgeaudio 540A V2 int sm (Ocr-read)
Page 2
540A V2.0 SERVICE MANUAL
TABLE OF CONTENTS
Safety Precautions & Important Notes
Exploded Diagram
Input PCB Schematic (Power Supply)
Input PCB Schematic (Buffers and Switches)
Input PCB Schematic (Tone Control)
Input PCB Schematic (Protection Circuitry)
Input PCB Schematic (Headphone Driver)
Input PCB Layout (Top Side)
Input PCB Layout (Bottom Side)
Input PCB Assembly BOM
Voltage Select Switch PCB Schematic
Voltage Select PCB Layout (Top Side)
Voltage Select PCB Layout (Bottom Side)
Voltage Select PCB Assembly BOM
Mains PCB Schematic
Front Panel PCB Schematic
Mains & Front Panel PCB Layout (Top Side)
Mains & Front Panel PCB Layout (Bottom Side)
Mains & Front Panel PCB Assembly BOM
Amp PCB Schematic (Right Channel)
Amp PCB Schematic (Protection)
Amp PCB Schematic (Power Amp)
Amp PCB Schematic (Left Channel)
Amp PCB Layout (Top Side)
20
2|
22
23
24
25
26
27
Amp PCB Layout (Bottom Side)
28
Amp PCB Assembly BOM
29-3 |
Abus Module PCB Schematic
32
Abus Module PCB Layout (Top Side)
Abus Module PCB Layout (Bottom Side)
Abus PCB Assembly BOM
33
34
35
IC Pin Layout Details
36-42
