Brionvega rr 226 owners manual
This is the 20 pages manual for brionvega rr 226 owners manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from brionvega rr 226 owners manual (Ocr-read)
Page 1
Radio-phonograph general information 1 2 01 CUFFIE SUB AUX 1 PRE OUT AUX 2 DX DIFFUSORI SX MODELLO DEPOSITATO MADE IN ITALY rr- 262 radiofonografo ALIMENTAZIONE230V 50Hz INTERRUTTOREGENERALE I 0 ANTENNAIN 6 5 17 16 15 14 13 12 10 7 11 25 24 23 27 28 22 26 19 20 21 18 8 9 3 4 1 2 29 RR-226_UK.indd 2 21-11-2008 12:09:53
Page 2
i The Radio-phonograph rr-226 is a high-fidelity stereo system with stereo record player. It is composed of a central part which contains the radio receiver, amplifier, record player, CD MP3 player, control panel and connection panel, and 2 compression loudspeakers that can be fixed to the central part or arranged in the best position to improve the stereo effect. 3 1 2 3 4 7 8 9 10 11 12 13 14 Record player cover CD - MP3 Player AM-FM Radio frequency scale AM-FM Radio stored station scale Stored station selection knob Red stored radio station LED Green power LED Sound level indicator Radio station selection knob ON/OFF - Volume Level knob Bass adjustment knob Support stand 15 16 17 Middle tones adjustment knob Treble adjustment knob Audio balance adjustment knob 18 20 21 Control push-button panel Loudspeaker side fastening bracket Audio outlet holes 22 23 24 Auxiliary audio inputs (AUX1 - AUX2) Loudspeaker connections panel Main switch 25 26 27 Mains socket Central unit ventilation holes Audio connection for external subwoofer Pre-Out audio output 28 5 Loudspeakers 6 Record player 19 Loudspeaker carrying handle Headphone socket 29 RR-226_UK.indd 3 21-11-2008 12:09:55
