Bose lifestyle 135 cinemate 1sr speaker system rev 11
This is the 84 pages manual for bose lifestyle 135 cinemate 1sr speaker system rev 11.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from bose lifestyle 135 cinemate 1sr speaker system rev 11 (Ocr-read)
Page 1
1 Contents Safety Information ............................................................................................................................. 2 Electrostatic Discharge Sensitive (ESDS) Device Handling ......................................................... 2 Product Overview ............................................................................................................................. 3 Part List Notes .................................................................................................................................. 4 CineMate ® 1 SR System Packaged Part List .................................................................................. 5 Lifestyle® 135 System Packaged Part List .................................................................................. 6-7 Cinemate 1SR and Lifestyle ® 135 Sound Bar Main Assembly Part List ....................................... 8 Figure 1. Main Assembly Exploded View ..............................................................................................9 Cinemate 1SR Sound Bar DSP PCB Part List .........................................................................10-21 Lifestyle® 135 Sound Bar DSP PCB Part List.......................................................................22-32 CineMate 1SR and Lifestyle ® 135 Sound Bar AMP PCB Part List .......................................33-38 CineMate 1SR and Lifestyle® 135 Sound Bar Power Supply PCB Part List.......................39-44 CineMate 1SR Sound Bar I/O PCB Part List..........................................................................45-48 CineMate 1SR Sound Bar IR PCB Part List ................................................................................. 49 Lifestyle ® 135 Sound Bar IR PCB Part List .................................................................................. 50 CineMate 1SR and Lifestyle ® 135 Sound Bar AC Inlet PCB Part List ........................................ 51 CineMate 1SR and LS 135 Bass Module Main Part List ............................................................. 52 Figure 2. CineMate ® 1SR and Lifestyle ® 135 Bass Module Exploded View .......................................53 CineMate 1SR and LS 135 Bass Module Power/AMP PCB Part List ...................................54-59 CineMate 1SR and LS 135 Bass Module I/O PCB Part List ..................................................60-66 Sound bar Disassembly Procedures ......................................................................................67-70 Figure 3. Top Cover Screws ..............................................................................................................67 Figure 4. Phase Guide Speaker Screws ............................................................................................67 Figure 5. Phase Guide Wire Routing .................................................................................................67 Figure 6. Right Phase Guide Wire Routing ........................................................................................67 Figure 7. Twiddler ® Removal .............................................................................................................68 Figure 8. Front Tweeter Removal ......................................................................................................68 Figure 9. AdaptIQ ® Bezel Removal ....................................................................................................68 Figure 10. DSP Removal ..................................................................................................................68 Figure 11. Amp PCB Removal ..........................................................................................................69 Figure 12. I/O PCB Removal .............................................................................................................69 Figure 13. IR/LED PCB Mesh ...........................................................................................................69 Figure 14. IR/LED PCB ......................................................................................................................69 Figure 15. AC PCB ............................................................................................................................70 Figure 16. Power Supply PCB Removal ............................................................................................70 Lifestyle 135 Bass Module Disassembly Procedures ...........................................................71-72 Figure 17. Rear Cover Removal ........................................................................................................71 Figure 18. AC Wire Harness ..............................................................................................................71 Figure 19. Connector Cover Removal ...............................................................................................71 Figure 20. DSP PCB Removal ..........................................................................................................72 Figure 21. Heat Sink Removal ...........................................................................................................72 Figure 22. Power Supply PCB Removal ...........................................................................................72 Setting up a Computer to Issue TAP Commands ......................................................................... 73 TAP Connections to Sound Bar and Bass Module ....................................................................... 74 Figure 23. TAP Cable 299656 ...........................................................................................................74 Figure 24. TAP Cable 264565 ...........................................................................................................74 Figure 25. Soundbar TAP Port ..........................................................................................................74 Pairing a Soundbar to a Bass Module ............................................................................................... 75 Setting The Region Variant - Cinemate 1SR Only ....................................................................... 76 Figure 26. Transducer and PCB Identification ....................................................................................76 Lifestyle ® 135 Prformance Verification Procedures ..............................................................77-78 CineMate 1SR Performance Verification Procedures..........................................................79-81 Miscellaneous TAP Commands .....................................................................................................82 Revision History .............................................................................................................................. 83
Page 2
2 1. Parts that have special safety characteristics are identified by the symbol on schematics or by special notes on the parts list. Use only replacement parts that have critical characteristics recommended by the manu- facturer. 2. Make leakage current or resistance measurements to determine that exposed parts are acceptably insulated from the supply circuit before returning the unit to the customer. Use the following checks to perform these measurements: A. Leakage Current Hot Check-With the unit completely reassembled, plug the AC line cord directly into a 120V AC outlet. (Do not use an isolation transformer during this test.) Use a leakage current tester or a metering system that complies with American National Standards Institute (ANSI) C101.1 Leakage Current for Appliances and Underwriters Laboratories (UL) 6500/60065 / IEC 60065 paragraph 9.1.1. With the unit AC switch first in the ON position and then in OFF position, measure from a known earth ground (metal waterpipe, conduit, etc.) to all exposed metal parts of the unit (antennas, handle bracket, metal cabinet, screwheads, metallic overlays, control shafts, etc.), especially any exposed metal parts that offer an electrical return path to the chassis. Any current measured must not exceed 0.5 milliamp. Reverse the unit power cord plug in the outlet and repeat test. ANY MEASUREMENTS NOT WITHIN THE LIMITS SPECIFIED HEREIN INDICATE A POTENTIAL SHOCK HAZARD THAT MUST BE ELIMINATED BEFORE RETURNING THE UNIT TO THE CUSTOMER. B. Insulation Resistance Test Cold Check-(1) Unplug the power supply and connect a jumper wire between the two prongs of the plug. (2) Turn on the power switch of the unit. (3) Measure the resistance with an ohmmeter between the jumpered AC plug and each exposed metallic cabinet part on the unit. When testing 3 wire products, the resistance measured to the product enclosure should be between 2 and infinite MOhms. Also, the resistance measured to exposed input/output connectors should be between 4 and infinite MOhms. When testing 2 wire products, the resistance measured to exposed input/output connectors should be between 4 and infinite MOhms. If it is not within the limits specified, there is the possibility of a shock hazard, and the unit must be repaired and rechecked before it is returned to the customer. ELECTROSTATIC DISCHARGE SENSITIVE (ESDS) DEVICE HANDLING This unit contains ESDS devices. We recommend the following precautions when repairing, replacing or transporting ESDS devices: - Perform work at an electrically grounded work station. - Wear wrist straps that connect to the station or heel straps that connect to conductive floor mats. - Avoid touching the leads or contacts of ESDS devices or PC boards even if properly grounded. Handle boards by the edges only. - Transport or store ESDS devices in ESD protective bags, bins, or totes. Do not insert unprotected devices into materials such as plastic, polystyrene foam, clear plastic bags, bubble wrap or plastic trays. SAFETY INFORMATION CAUTION: THE BOSE ® LIFESTYLE ® 135 AND CINEMATE ® 1 SR, CONTAINS NO USER SERVICE- ABLE PARTS. TO PREVENT WARRANTY INFRACTIONS, REFER SERVICING TO WARRANTY SERVICE STATIONS OR FACTORY SERVICE. PROPRIETARY INFORMATION THIS DOCUMENT CONTAINS PROPRIETARY INFORMATION OF BOSE CORPORATION WHICH IS BEING FURNISHED ONLY FOR THE PURPOSE OF SERVICING THE IDENTIFIED BOSE PRODUCT BY AN AUTHORIZED SERVICE CENTER OR OWNER OF THE BOSE PRODUCT, AND SHALL NOT BE REPRODUCED OR USED FOR ANY OTHER PURPOSE.
