Bose freespace business system controller
This is the 34 pages manual for bose freespace business system controller.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from bose freespace business system controller (Ocr-read)
Page 1
2 TABLE OF CONTENTS Electrostatic Discharge Sensitive (ESDS) ....................... 2 Safety Information ....................... 3 Specifications ...................... 4 Specifications ........................ 5 Figure 1. Block Diagram ......................6 Figure 2. Input Connections .....................7 Figure 3. Output Connections .......................7 Figure 4. Rear Panel View .....................7 Disassembly / Assembly procedures ..................... 8 Figure 5. Exploded View .........................10 Test Procedures ............................. 11 Test Set-Up Parameters ............................ 11 Part List Notes .................................... 14 Main Assembly Parts List ............................... 15 Figure 6. Main Assembly ............................15 Electrical Parts List .................................... 16 Packaging ............................................ 21 Figure 7. Packaging .................................21 Main PCB Schematic ................................... 22 REV 0/ REV1 Main PCB Schematic ....................................... 23 REV 0/ REV1 Main PCB Schematic .................................... 24 REV 0/ REV1 Main PCB Schematic ........................................ 25 REV 0/ REV 1 I/O PCB Schematic ...................................... 26 REV 1 I/O PCB Schematic ....................................... 27 REV 1 I/O PCB Schematic ........................................ 28 REV 1 I/O PCB Schematic ......................................... 29 REV 1 I/O PCB Schematic ............................................. 30 REV 0 I/O PCB Schematic .............................................. 31 REV 0 I/O PCB Schematic ............................................... 32 REV 0 I/O PCB Schematic ................................................. 33 REV 0
Page 2
3 PROPRIETARY INFORMATION THIS DOCUMENT CONTAINS PROPRIETARY INFORMATION OF BOSE ¨ CORPORATION WHICH IS BEING FURNISHED ONLY FOR THE PURPOSE OF SERVICING THE IDENTIFIED BOSE PRODUCT BY AN AUTHORIZED BOSE SERVICE CENTER OR OWNER OF THE BOSE PRODUCT, AND SHALL NOT BE REPRODUCED OR USED FOR ANY OTHER PURPOSE. CAUTION: THE BOSE ¨ FREESPACE ¨ SYSTEM CONTROLLER CONTAINS NO USER-SERVICEABLE PARTS. TO PREVENT WARRANTY INFRACTIONS, REFER SERVICING TO WARRANTY SERVICE STATIONS OR FACTORY SERVICE. Electrostatic Discharge Sensitive (ESDS) Device Handling This unit contains ESDS devices. We recommend the following precautions when repairing, replacing or transporting ESDS devices: ¥ Perform work at an electrically grounded work station. ¥ Wear wrist straps that connect to the station or heel straps that connect to conductive floor mats. ¥ Avoid touching the leads or contacts of ESDS devices or PC boards even if properly grounded. Handle boards by the edges only. ¥ Transport or store ESDS devices in ESD protective bags, bins, or totes. Do not insert unprotected devices into materials such as plastic, polystyrene foam, clear plastic bags, bubble wrap or plastic trays.
