Page 1
BLAUPUNKT SPECIFICATIONS - VA1400, 1 C HANNEL AMPLIFIER – 1 – All power ratings conform to CEA-2006 standards. P ARAMETER/FEATURE VA1400 Channels 1 Size ( L x W x D) without trim panels 15.1x9.1x2.4 inches (382x231x60mm) Weight 14.5 lbs. (6.6 kg) Spade screw speaker terminals? YES Maximum terminal wire size 10 ga. Subsonic filter YES (10 Hz) Separate f ont/rear or left/right gains? N/A Fuse TypeATC spade -Two 40A Speaker short, short to +12V, and short to g ound p otection? YES High, low, and reverse voltage p otection? YES Power output transistors Low QZ MOSFET Power supply transistors MOSFET Minimum speaker impedance (non-bridged) 2 ohms (bridged) N/A PERFORMANCE DATA Rated power output @ 0.1% THD, 14.4V (CEA-2006) 1 channel into 4 ohms(watts rms) 1 x 100 W 1 channel into 2 ohms (watts rms) 1 x 600 W Max Dynamic Power (watts rms) 700W Total Harmonic Distortion @ full power 0.3% THD Signal/Noise ratio (gain cont ols in center) Measured @ 1 watt / 1 kHz dBA>80 Measured @ full rated power (0.1% THD) dBA >100 Damping factor >100 Frequency response (full-range mode) 50 - 250 Hz High-pass c ossover frequency limits N/A Low-pass c ossover frequency limits 50 H z - 250 Hz (variable), 12dB/oct Input impedance 10 kohms Input signal voltage cont ol range 0.3 - 8.0 vrms Current Draw @ 13 8 VDC (typical values @ X watts / Efficiency %) @ full rated power, unbridged(@ 4 ohms) 50 A (50%) @ 33% rated power, unbridged(@ 4 ohms) 30 A (35%) @ idle (@ 4 ohms) 1 A Minimum battery voltage to maintain rated power 12.6 VDC Usable battery voltage 10 - 16 VDC Trigger line voltage range 10 - 16 VDC Trigger line current draw < 20 mA Tun on delay time @ 2.0 seconds Thermal shutoff temperature (average heat-sink temp) @ 85˚ C (185˚ F) This information is subject to change without notice!
Page 2
– 2 – ASSEMBLY & M OUNTING
