Blaupunkt Ravenna RCM 168 Owners Manual
This is the 24 pages manual for Blaupunkt Ravenna RCM 168 Owners Manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from Blaupunkt Ravenna RCM 168 Owners Manual (Ocr-read)
Page 1
2 6 8 1213 14 1 15 2 3 4 5 9 10 11 7 16 17 2 3 9 10 Remote control RC 08 (optional)
Page 2
26 Display The display consists of three fields and varies according to the operati\ ng mode and function. Display field 1: Radio mode Memory banks and wavebands Brief indication of preset station (e.g. P1) Cassette mode CAS - cassette inserted MTL - tape type Changer mode Current track Audio Numeric and graphic representation of vo- lume and audio settings DSC Permanent display for DSC programming. Graphic representation of the adjusted vo- lume level. Display field 3: Active functions - Stereo - Cassette inserted - CD changer connected LD - Loudness Radio mode AF - Alternative Frequency for RDS PTY - RDS programme type TA - Priority for traffic information TP - Traffic programme station lo - Seek tuning sensitivity Cassette mode RPT - Repeat function - Dolby noise reduction Changer mode RPT - Repeat function MIX - Tracks played at random Display field 2: Radio mode Radio frequency or station name PTY programme type Clock display Cassette mode TAPE1/TAPE2 - side of tape playing Active functions (e.g. CPS) Clock display Changer mode Current CD playing CD time (elapsed time), CD name, CD num- ber and Brief indication of changes in function Clock display DSC Serves as display and input field during DSC programming Clock display Miscellaneous Indicates new source (e.g. when changing from radio to cassette) and active functions (e.g. BASS, SCAN)
