Blaupunkt IVMS 7001 Owners Manual
This is the 11 pages manual for Blaupunkt IVMS 7001 Owners Manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from Blaupunkt IVMS 7001 Owners Manual (Ocr-read)
Page 1
12 DEVICE OVERVIEW 5.6" and 7" ON OSD SRC VIDEO 9 1 2 3 4 5 6 11 10 8 7 15.6"/ 7" TFT LCD screen for headrests 2On/off switch 3Key for screen menu display (OSD menu) 4Up menu 5Down menu 6AV channel setting (AV1 - AV2 - AV3 - AV4 - AV5)7Headphone socket 8Video input (internal) 9Connecting cable :Interface cable ;AV signal converter unit
Page 2
13 ENGLISH TA BLE OF CONTE NTS Notes / Accessories .............. 14 Fitting ..................................... 14 Prepare the working area .............. 14 Mark out the dimensions ................ 15 Carefully cut open the headrest cover ............................................. 15 Open the headrest and remove filling and other items ..................... 15 Lay the cable through the headrest ........................................ 16 Insert the mounting frame in the headrest .................................. 16 Insert the monitor .......................... 16 Check and adjust the monitor then apply the Velcro strips ................... 17 Removal ................................. 17 OSD functions ........................ 18 Main menu .................................... 18 Sub-menu ..................................... 18 Technical data ........................ 19 Guarantee .............................. 20
