Arcam P38 Owners Manual
This is the 18 pages manual for Arcam P38 Owners Manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from Arcam P38 Owners Manual (Ocr-read)
Page 1
e-2 safety guidelines i mportant safety instructions This product is designed and manufactured to meet strict quality and safety standards. However, you should be aware of the following installation and operation precautions. 1. Take heed of warnings and instructions You should read all the safety and operating instructions before operating this equipment. Retain this handbook for future reference and adhere to all warnings in the handbook or on the equipment. 2. Water and moisture The presence of electricity near water can be dangerous. Do not use the equipment near water – for example next to a bathtub, washbowl, kitchen sink, in a wet basement or near a swimming pool, etc. 3. Object or liquid entry Take care that objects do not fall and liquids are not spilled into the enclosure through any openings. Liquid- filled objects such as vases should not be placed on the equipment. 4. Placing the equipment Only use a rack or shelf that is stable and strong enough to support the weight of this equipment. 5. Ventilation Do not place the equipment on a bed, sofa, rug or similar soft surface, or in an enclosed bookcase or cabinet, since ventilation may be impeded. 5. Heat Locate the equipment away from naked flames or heat- producing appliances such as radiators, stoves or other appliances that produce heat. 6. Climate The equipment has been designed for use in moderate climates and in domestic situations. 8. Cleaning Unplug the unit from the mains supply before cleaning. The case should normally only require a wipe with a soft, lint-free cloth. Do not use chemical solvents for cleaning. We do not advise the use of furniture cleaning sprays or polishes as they can cause permanent white marks. 9. Power sources Only connect the equipment to a power supply of the type described in the operating instructions or as marked on the equipment. The primary method of isolating the equipment from the mains supply is to remove the mains plug. The equipment must be installed in a manner that makes disconnection possible. 10. Power-cord protection Power supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them. Pay particular attention to the point where they exit from the equipment. 11. Power lines Locate any outdoor antenna/aerial away from power lines. 12. Non-use periods If the equipment is not being used for an extended period, we recommend that you unplug the power cord of the equipment from the outlet, to save power. 13. Abnormal smell If an abnormal smell or smoke is detected from the equipment, turn the power off immediately and unplug the equipment from the wall outlet. Contact your dealer and do not reconnect the equipment. 14. Servicing You should not attempt to service the equipment. Contact your dealer to arrange servicing.15. Damage requiring service The equipment should be serviced by qualified service personnel when: A. the power-supply cord or the plug has been damaged, or B. objects have fallen, or liquid has spilled into the equipment, or C. the equipment has been exposed to rain, or D. the equipment does not appear to operate normally or exhibits a marked change in performance, or E. the equipment has been dropped or the enclosure damaged. Safety compliance This equipment has been designed to meet the IEC/EN 60065 international electrical safety standard. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. c lass i product This equipment is a Class I electrical appliance. It requires safety connection to electrical earth (ground in the U.S.). M Any of th Es E I t EM s ArE co MM on s Ens E P r Ec A ut Ions but, for your own s AfE ty And to Ensur E th At you do not dAMAGE thE un It, w E r Eco MME nd th At you r EAd th EM. RISQUE DE CHOC ELECTRIQU E NE P AS OUVRI R ATTENTION CA UTION RISK OF ELECTRI C SHOCK DO NO T OPEN CAUTION: To reduce the risk of electric shock, do not remove cover (or back). No user serviceable parts inside. Refer servicing to qualified service personnel. WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture. The lightning flash with an arrowhead symbol within an equilateral triangle, is intended to alert the user to the presence of uninsulated dangerous voltage within the products enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the product. CAUTION: In Canada and the USA, to prevent electric shock, match the wide blade of the plug to the wide slot in the socket and insert the plug fully into the socket.
Page 2
e-3 english welcome Thank you and congratulations for purchasing your Arcam FMJ Amplifier. Arcam has been producing specialist audio products of remarkable quality for over three decades and the new A38 and P38 amplifiers are the latest in a long line of award winning HiFi. The design of the FMJ range draws upon all of Arcams experience as one of the UKs most respected audio companies, to produce Arcams best preforming Stereo amplifiers yet; designed and built to give you years of listening enjoyment. This handbook is intended to give you a detailed guide to using both the A38 Integrated Amplifier and P38 Power Amplifier systems. It starts by giving advice on installation, moves on to describe how to use the product and finishes with additional information on the more advanced features. Use the contents list shown on this page to guide you to the section of interest. We hope that your FMJ Amplifier will give you years of trouble-free operation. In the unlikely event of any fault, or if you simply require further information about Arcam products, our network of dealers will be happy to help you. Further information can also be found on the Arcam website at www.arcam.co.uk. The FMJ development team contents safety guidelines ....................................... E-2 Important safety instructions ...........................E-2 Safety compliance ................................................ E-2 welcome ...................................................... E-3 overview ..................................................... E-4 Placing the unit ..................................................... E-5 Power ........................................................................\ . E-5 Interconnect cables .............................................. E-5 A38 connections ....................................... E-6 Audio inputs ........................................................... E-7 Recording loops .................................................... E-7 Phono input ............................................................ E-7 Pre-/power-amplifier connections .................E-7 Controlling A38 from a second room............ E-7 loudspeakers ............................................. E-8 Connecting loudspeakers to the A38/P38 . . E-8 Single wiring ........................................................... E-9 Bi-wiring ................................................................... E-9 Bi-amping ................................................................ E-9 A38 operation ......................................... E-10 Switching the A38 on ........................................E-10 Changing the volume .......................................E-10 Selecting an audio source ...............................E-10 Recording an audio source .............................E-10 A38 setup................................................. E-11 Configuring your A38 amplifier .....................E-11 remote control ........................................ E-12 The CR90 Universal remote controller ........E-12 Source keys ............................................................ E-12 Amp commands .................................................. E-13 P38connections...................................... E-14 Connecting to loudspeakers ..........................E-14 Other connections .............................................. E-14 Remote switching ............................................... E-15 specifications .......................................... E-16 Troubleshooting .................................................. E-17 Remote-control codes ......................................E-17 product guarantee ................................E-18
