Contents List
Contents list
Circuit description
Service guide
Circuit diagrams
Component overlays
Circuit board parts list
General assembly parts list
Page 38
A65 Plus General Assembly
ITEM 230V 115V 100V SILVER BLACK DESCRIPTION WHERE USED QTY
A L817RC REMOTE CONTROL 1
9 E091AY E091AYB FRONT PANEL ASSY 1
7 E829CP E830CP COVER PLATE 1
43 HA4VOGS HA4V06B M4 X 6mm SCREW 4
21 58483028 HOLTECH + L818$W WA65| 1A 1
17 C12126 012256 C12256 FUSE FUSE AND SPARE 2
1.25A T 215A T 2.5A T
1 E033RP REAR PANEL 1
73 E802AP DAMPING PAD (1 PER) L600 L700 (2 PER) RLY1 SEE 4
L881AY FOR POSITIONING
76 E804AP BLK FELT WASHER 4
55 E806M| MAINS INSULATOR UNDER MOTHER PCB 1
3 E062AY DiVA LOW AMP & TUNER CHASSIS ASSY 1
2 E81ZSP SUB PANEL 1
59 E827PM SUPPORT SPACER UNDER TX 1
36 E82801 FOAM PAD RES. CAPS 1
57 E83001 TX GASKET UNDER TX 1
1O E855PM SELECTOR KNOB 1
69 E856MC HEAT SINK CLAMP 2
15 E856PM BAS/TRB/BAL KNOB 3
11 E861 PM PUSH BUTTON 3
14 E863PM VOLUME KNOB 1
12 E072AY DIVA EXTENDED POWER BUTTON 1
13 E879PM FOOT 4
67 E8798L CONFIGURATION LABEL 1
71 E908MC KOOL PAD 2
16 F022 FUSEHOLDER COVER 2
5 F037 TOROID CLAMP 7OMM FOR TX1 1
56 F038 RUBBER WASHER 90MM OD ON TOP OF TX 1
66 F062 FUSE CLIP PCB 1
64 F065 CABLE CLIP FOR PROCESSOR SWITCH WIRE & 1
TX SCREEN
74 F164 DAMPING STRIP TOP OF FRONT 400MM
51 F185 SNAP-IN SPACER 2
52 H006 SNAP-IN SPACER PCB 1
75 HA3V06A MC TORX P/H M3X6 STZP Sub panel/display 7
42 HA3V10A M3 X 10mm SCREW MOTHER PCB 6
46 HA4A1ZB M4 X 12mm SCREW RR PAN E' 2
47 HA4A4SB M4 X 45mm SCREW HEAT SINK FXGS 4
48 HA6K50A M6 X 50MM HEX BOLT TX FXG 1
40 HE6VOGB No.6 X 6mm SCREW COVER, PCB, SUB-PAN 7
41 HF4V09B No.4 x 9mm SCREW RR PAN. PHONOS, COVER 13
49 HJ4AO0A M4 NUT RR PAN E' 2
50 HJ4COOD M4 WAISTED NUT RR PAN E' 1
